ASTM JIS G3313 Electrogalvanized Steel Angle 6mm Thickness 2000mm Length
ASTM JIS G3313 Electrogalvanized Steel Angle 6mm Thickness 2000mm Length
Product Descriptions:
|
Commodity
|
Electrogalvanized Steel Angle
|
|
Standard
|
ASTM, JIS, DIN, EN, GB
|
|
Grade
|
A36, SS400, Q195-Q345
|
|
Technique
|
Hot Rolled
|
|
Type
|
Equal Angle Bar / Unequal Angle Bar
|
|
Size
|
20*20*3mm - 200*200*20mm
|
|
Length
|
5m, 10m, 12m or as required
|
|
Payment Terms
|
T/T, L/C
|
|
Delivery Time
|
20 days after get the deposit
|
|
Packing
|
In bundles, standard export packing
|
| Grade | Chemical Composition | Mechanical Properties | ||||||
| C | Mn | Si | S | P | Yield | Tensile | Elongati | |
| Strength Mpa | Strenth Mpa | -on % | ||||||
| Q195 | 0.06-0.12 | 0.25-0.50 | ≤0.30 | ≤0.045 | ≤0.05 | ≥195 | 315-430 | ≥33 |
| Q215 | 0.09-0.15 | 0.25-0.55 | ≤0.30 | ≤0.05 | ≤0.045 | ≥215 | 335-450 | ≥27 |
| Q235 | 0.12-0.20 | 0.30-0.67 | ≤0.30 | ≤0.045 | ≤0.04 | ≥235 | 375-500 | ≥26 |
| Q345 | ≤0.20 | 1.00-1.60 | ≤0.55 | ≤0.04 | ≤0.04 | ≥345 | 470-630 | ≥22 |
Product Details:
Top Steel will test steel angle product size before shiping. Ensure that the product is meet your order requirement.
Applications:
Packing & Shipping:
About us:
WHY CHOOSE US?
1.Competitive price and high quality from our own factory.
2.Our group having own three factories , two trading companies and one logistics company .Can supply one-stop service from products purchasing to transport.
3.Approved by the ISO 9001,CE,BV,SGS,ABS,API every year.
4.Smooth production ability 60,000tons each month .
5.Strict quality control , ensure any product satisfied with yours application .
6.OEM/ODM , Free of charges of Logo design and printing on your goods
