Small Four Wheel Drive Loader Compact Articulated 79hp 58kw Power
Small hub Axle Compact Articulated Wheel Loader, 58kw 79hp Power Wheeled Front End Wheel Loader
1. Products Description
we need the construction machine to do heavy work, obviously it has to be efficient, take loader as an example, the bucket should shovel as much as possible, the loader should be stable while working, the control should be flexible and easy, the malfunction rate is low of course.
MCLLROY wheel Loader is a kind of front wheel loader with single bucket ,articulated and hydraulic unloading. It has been developed and designed in accordance with user requirements, reference models after absorption of domestic and overseas advanced similar structural features and advanced technology.
2. Specification
| MODEL | MCL 932/ZL 932 | Metric Units |
| ENGINE | Engine Model | Yun Nei 490 Supercharged |
| RPM | 2400 | |
| Rated Power | 58 kW | |
| Emissions | EU Stage II | |
| WEIGHTS | Operating Weight | 3670 kg |
| Rated Load | 1800 kg | |
| BUCKETS | Bucket Capacities | 0.6-1.0 m³ |
| TRANSMISSION | Max. Travel Speed | 28 km/h |
| Gear Box | CVT 265 torque converter |
|
| Alex | Small hub | |
| Axle Base | 2210 mm | |
| Brake | Disc Brake | |
| HYDRAULIC SYSTEM | Hydraulic Cycle time - lift | ≤ 7 s |
| DIMENSIONS(APPROXIMATE) | Min. Ground Clearance | 290 mm |
| Wheel Base | 1490 mm | |
| Reach at Max.Dump Height | 3200 mm | |
| Dump Reach | ≤ 650 mm | |
| Overall Length - With Bucket | 5300 mm | |
| Overall Width | 1820 mm | |
| Overall Height | 2670 mm | |
| OPERATING SPECIFICATIONS | Tyre Size | 20.5-16 |
| Breakout Force | 40 KN | |
| Joystick | Machanical | |
| Min. turning radius | ≤ 7000 mm | |
| STANDARD EQUIPMENT | Hour meter | Yes |
| Tool Box | Yes | |
| Dual Hight&Low Speed Handle | Yes |
3. Details and Advantages
The main components of the loader are used brand-name manufacturer's products, interchangeability of good, reliable, well-resourced parts.
1) Frame:High Reliability Upgraded & enhanced front & back frames ,and reinforced counterweight.
2) Cab:Comfortable Operation Ergonomic design for more comfortable operation.
3) Convenient maintenance leading-out grease fitting is convenient for lubrication.
4) Ladder with wide steps and well-placed hand holds to ease entry and exit from the cabin.
4.Why Choose Us
We closely match the needs of customers with our specialty, balance the price and give
customers the best quality product possible.
Our motto is that:
At the same price, we strive to offer the best quality.
Under the same configuration, we strive for the lowest price.
We believe that with our professionalism, quality, price and service we will
achieve a win-win cooperation with you !
Similar Model:
Cat 903D/906M/907M/908M
XCMG LW156/LW160/LW180/LW186/LW200
Liugong 816C
SDLG LG916 LG918 L918
