48v 200ah 51.2v Renewable Energy Storage Battery Stackable Portable
Price:
negotiated price
MOQ:
2
Delivery Time:
5-14 work days
Brand:
OCELL
Product Description
48V Home Battery Storage 48v 200ah 51.2V Stackable Portable Renewable Energy Storage Battery
In the process of cell manufacturing, we strive for perfection and continue to optimize production processes to ensure cell yield and batch consistency. Our consistent aim is to treat defect zero tolerance.
All of our lithium iron phosphate power battery series have been approved UL , CB , UN38.3 and other certifications. The cell is safe, reliable and stable.If you have the opportunity to come to China, we welcome you to visit our factory and take you to enjoy Chinese delicious food.
ESS Parameters
|
|
OCESS-5K-5K-A2
|
OCESS-5K-10K-A2
|
OCESS-10K-15K-A2
|
|
BATTERY
|
|
|
|
|
Battery Module
|
1
|
2
|
3
|
|
Battery Energy
|
5.12kWh
|
10.24kWh
|
15.36kWh
|
|
Battery Capacity
|
100Ah
|
200Ah
|
300Ah
|
|
Weight
|
83kg
|
135kg
|
187kg
|
|
Dimension Lx DxH
|
600 x 165 x 840mm
|
600 x 165 x 1260mm
|
600 x 165 x 1260mm
|
|
Solar Charge Type
|
MPPT
|
||
|
Battery Rated Voltage
|
51.2V
|
||
|
Maximum Output Power
|
5KW
|
||
|
PV Charging Current Range
|
0~80A
|
||
|
PV Operating Voltage Range
|
120~500V
|
||
|
MPPT Voltage Range
|
120~450V
|
||
|
AC CHARGE
|
|
|
|
|
Maximum Charge Power
|
3150W
|
||
|
AC Charging Current Range
|
0~60A
|
||
|
Rated Input Voltage
|
220/230Vac
|
||
|
lnput Voltage Range
|
90~280Vac
|
||
|
AC OUTPUT
|
|
|
|
|
Rated Output Power
|
5KW
|
||
|
Maximum Output Current
|
30A
|
||
|
Frequency
|
50Hz
|
||
|
Overload Current
|
35A
|
||
|
Maximum Peak Power
|
10KVA
|
||
|
Power Factor
|
1
|
||
|
Rated Output Voltage (VAC)
|
230Vac
|
||
|
Auto Switch Period
|
<10ms
|
||
|
THD
|
3%
|
||
|
GENERAL DATA
|
|
|
|
|
Communication
|
RS485/CAN/WIFI(optional)
|
||
|
Storage time / temperature
|
6 months @25℃ ;3 months @35℃ ;1 months @45℃
|
||
|
Charging temperature range
|
0~45℃
|
||
|
Discharging temperature range
|
-10~45℃
|
||
|
Operation Humidity
|
5% ~ 85%
|
||
|
Nominal Operation Altitude
|
<2000m
|
||
|
Cooling Mode
|
Electric Fan
|
||
|
Noise
|
60DB
|
||
|
Cycle Life
|
6000 cycles at 80% DOD
|
||
|
Calendar Life
|
10 years
|
||
|
Ingress Protection Rating
|
IP20
|
||
|
Recommended Operation Environment
|
Indoor
|
||
|
Installation Method
|
Floor Mounting
|
||
|
Certification
|
UN38.3, MSDS
|
||
Q: What is a solar inverter or energy storage battery?
A:It is a combination of the two, is a battery and inverter integrated energy storage system, mainly used in residential and small commercial or some laboratories.
Q: What material is this battery made of?
A: Our energy storage batteries are lithium iron phosphate batteries with the best safety and stability,
Q: How does a solar inverter work?
A: A solar inverter takes the DC electricity generated by the solar panels and converts it into
AC electricity using electronic circuitry. This AC electricity can then be used by homes and businesses, or fed back into the
grid.
AC electricity using electronic circuitry. This AC electricity can then be used by homes and businesses, or fed back into the
grid.
Q: How much capacity does this ESS support?
A: Our specifications are 5kwh, 10kwh, 15kwh, 20kwh, 25kwh. If you need larger ones, we can accept customization. There must be a design scheme that meets your expectations.
Q: How difficult is your All in one energy storage system to install?
A: Our all-in-one machine adopts the design of standing cabinet, which is very convenient to install and use. It does not require you to carry out tedious operation. Once the product is received, you can directly connect to your power grid
Q: What should I do if something goes wrong with the product?
Q: What should I do if something goes wrong with the product?
A: Please rest assured that we will test every product before it leaves the factory to make sure that every function can be used normally and there are no safety problems. Only then can we allow it to be packaged and shipped. Secondly, we have quality assurance. After you purchase the product, we have after-sales service. Please contact us at any time.
