ISO9001 CE Circulating Lubrication System Oil Lubricating Machine 25L/Min
LBZ-25 GDR Type Double High Pressure Lube Oil Station GDR-B2.5/25 Y112M-6 B35
Lube Oil Station
GDR type double high pressure series high (low) pressure thin oil station is suitable for the thin oil circulation lubrication system of large equipment such as mills and rotary kilns equipped with double sliding shoe dynamic and static bearings. The viscosity grade of the working medium is N22～N460 (equivalent to Various industrial lubricating oils based on ISO VG22～460); if the low-pressure pump oil volume is divided into two oil supply pipelines, a set of double high-pressure high (low) pressure thin oil stations can be used instead of two ordinary high (low) pressure pumps Thin oil station [such as the smaller one of GXYZ type A series high (low) pressure thin oil station].
Product Paramerters
| Parameters | Type | GDR-B2.5/16 | GDR-B2.5/25 | GDR-B2.5/40 | GDR-B2.5/63 | GDR-B2.5/100 | GDR-B2.5/125 | |
| low pressure system | Pump unit model | LBZ-16 | LBZ-25 | LBZ-40 | LBZ-63 | LBZ-100 | LBZ-125 | |
| Flow | 16L/min | 25L/min | 40L/min | 63L/min | 100L/min | 125L/min | ||
| Oil supply pressure | ≤0.4 MPa | |||||||
| Oil supply temperature | 40±3℃ | |||||||
| Motor | Model | Y90S-4,V1 | Y100S-4,V1 | Y112S-4,V1 | ||||
| Power | 1.5 KW | 2.2 KW | 4 KW | |||||
| Speed | 1450 r/min | 1450 r/min | 1450 r/min | |||||
| Fuel tank capacity m3 | 0.93 | 1.25 | 1.7 | |||||
| High pressure system | Pump unit model | 2.5MCY14-1B | ||||||
| Flow | 2.5 L/min | |||||||
| Oil supply pressure | 31.5 MPa | |||||||
| Motor | Model | Y112M-6 B35 | ||||||
| Power | 2.2 Kw | |||||||
| Speed | 940 r/min | |||||||
| Filtration accuracy m2 | 0.08~0.12 | |||||||
| Filter oil volume m3/h | 5 | 8 | 12 | |||||
| Cooling Area m2 | 2 | 5 | 7 | |||||
| Electric heating power Kw | 3 x 1 | 3 x 2 | 3 x 2 | |||||
| Dimension (mm) | 1560*1000*550 | 1750*1100*600 | 1800*1200*800 | |||||
