12m Length Universal I Beam For Machinery Manufacturing Frame Structure
i beam 12 m length price in china i beam 200 x 100 weight 225mm x 300mm 150*150*30 12# steel i-beam
Universal Beam
A universal beam is a length of structural steel that has a cross section in the shape of an “I” or an “H”. That is why the material is also known as an I-beam or H-beam. The web (vertical part of the “H” or “I”) withstands hard forces, while the flange (horizontal part of the “H” or “I”) endures bending movements. Sizes are determined by the web, flange and weight per metre.
A universal beam is often used in construction and civil engineering applications, especially as support for buildings to ensure that the structure is strong enough.
| Product Name | I Beam Steel |
| Size | 100mm-900mm |
| Wall thickness | 1.5mm-28mm |
| Length | 6m-12m,by customer's requiremnts |
| Internatioanal Standard |
ISO9001-2008 /ISO 630 / JIS / ASTM |
| Standards | ASTMA53/ASTM A573/ASTM A283/Gr.D/BS1387-1985/GB/T3091-2001,GB/T13793-92,ISO6 |
| Materials | Q195.Q215Q235B.Q345B.S235JR/S235/S355JR/S355SS440/SM400A/SM400B |
| Product Category | Metallurgy,Mineral & Energy |
| Technique | HOT ROLLED |
| Packing | 1.Big OD:in bulk |
| 2.Small OD:packed by steel strips | |
| 3.woven cloth with 7 slats | |
| 4.according to the requirements of customers | |
| Usage | Mechanical & manufacture Steel strcuture |
| Country of origin | China |
| Productivity | 15000 Metric Tons pet Month |
| Another Name | Hot rolled mild steel I beam,I beam, H beam , steel beam, beam |
| Surface processing | you can Galvanized coatedor as your request |
| Technical | Hot rolled mild steel |
| 规格 | 重量/米 | 规格 | 重量/米 |
| 100*100*6*8 | 17.2 | 350*350*12*19 | 137 |
| 125*125*6.5*9 | 23.8 | 390*300*10*16 | 107 |
| 148*100*6*9 | 21.4 | 396*199*7*11 | 56.7 |
| 150*75*5*7 | 14.3 | 400*200*8*13 | 66 |
| 150*150*7*10 | 31.9 | 400*400*13*21 | 172 |
| 175*175*7.5*11 | 40.4 | 400*408*21*21 | 197 |
| 194*150*6*9 | 31.2 | 414*405*18*28 | 233 |
| 198*99*4.5*7 | 18.5 | 440*300*11*18 | 124 |
| 200*100*5.5*8 | 21.7 | 446*199*8*12 | 66.7 |
| 200*200*8*12 | 50.5 | 450*200*9*14 | 76.5 |
| 200*204*12*12 | 56.7 | 482*300*11*15 | 115 |
| 244*175*7*11 | 44.1 | 488*300*11*18 | 129 |
| 248*124*5*8 | 25.8 | 496*199*9*14 | 79.5 |
| 250*125*6*9 | 29.7 | 500*200*10*16 | 89.6 |
| 250*250*9*14 | 72.4 | 582*300*12*17 | 137 |
| 250*255*14*14 | 82.2 | 588*300*12*20 | 151 |
| 294*200*8*12 | 57.3 | 594*302*14*23 | 175 |
| 294*302*12*12 | 85 | 596*199*10*15 | 95.1 |
| 298*149*5.5*8 | 32.6 | 600*200*11*17 | 106 |
| 300*150*6.5*9 | 37.3 | 692*300*13*20 | 166 |
| 300*300*10*15 | 94.5 | 700*300*13*24 | 185 |
| 300*305*15*15 | 106 | 792*300*14*22 | 191 |
| 340*250*9*14 | 79.7 | 800*300*14*26 | 210 |
| 346*174*6*9 | 41.8 | 900*300*16*28 | 243 |
| 350*175*7*11 | 50 |
Application:
1. Industrial structure of the steel structure bearing bracket.
2. Underground engineering steel pile and retaining structure.
3. Petrochemical and electric power and other industrial equipment structure
4. Large span steel bridge components
5. Ships, machinery manufacturing frame structure
6. The train, automobile, tractor beam bracket
7. Port of conveyor belt, high speed damper bracke
