Intelligent Yamaha Pick And Place Machine Ysm20r-Ysm20W For PCB Assembly
YAMAHA Intelligent Operation Precision Pick and Place Chip Mounter Machine Z LEX-YSM20R-YSM20W for PCB Assembly
Caters effectively to a wide range of production processes - it is also the world's fastest in its class.
-
Caters effectively to a wide range of production processes - it is also the world's fastest in its class
-
Note: components mounting speed (CPH) for a surface mounter with the 2-beam, 2-head layout. Based on Yamaha survey as at May 2014.
-
The "1 head solution" aims to deliver an ideal mounter that provides both high speed and versatility!
-
Wide support capability turns the concept of "limitless expansion" into a reality!
-
Numerous functions to support high-quality mounting are included as standard features.
-
Feeders and supply devices offering a high degree of freedom
Technical Parameters:
|
PCB size range |
Dual stage (only for 2-beam system) L 810 x W 490 to L 50 x W 50 mm |
||||||
|
Head/applicable components |
HM high-speed multi-purpose head (10 nozzles): 03015 mm to 45 x 45 mm, L 100, H 15 mm |
||||||
|
Mounting accuracy |
Cpk ≤ 1.0 ± 0.035 mm; 3σ ± 0.025 mm |
||||||
|
Mounting capability |
2-beam system with 2x HM head 90,000 CPH/63,500 CPH IPC9850 |
||||||
|
Number of component types |
Tape reel: 140 xed feeder plates, 8 mm width |
||||||
|
Power supply |
3-phase AC 200/208/220/240/380/400/416 V +/- 10% 50/60 Hz |
||||||
|
Air supply source |
0.45 MPa or more, in clean, dry state |
||||||
|
External dimension (excluding projections) |
L 1,374 x W 1,857 x H 1,445 mm |
||||||
|
Weight |
Approx. 2,050 kg |
||||||
