Rack Lifepo4 Battery Pack Rechargeable 48v 100ah Lithium Battery
High Qualify Rack 48v 100ah Rechargeable Lithium Battery
UFO High quality rack 48V Pylontech CATL Lifepo4 Cell Cabinet Battery is tailored for Storage Solar Module. It including different 5kwh 7.5kwh 10kwh, could support 15pcs connect in parallel. The low self-discharge, stable power supplier, has strengthening performance. The Smart BMS can well monitor the battery status, it can increase greater energy self sufficiency and security, reduce household electric charge.
1, High cycle life and deep cycle ability : >5000cycles @80% DOD @25, battery energy storage.
2, Intelligent monitoring :The monitor unit checks the charging and discharging current, voltage, battery surface temperature and ambient temperature automatically.
3, Light weight,high energy density standby power :
4, Safety : LiFePO4 Batteries adopt most advanced lithium ion technology, there is no risk of explosion and fire, it's designed for residential and commercial applications with absolute safety .
5,Intelligent BMS : the battery system adopt a special BMS, Highly performances battery management module is featured with voltage ,current and temperature protection , communication between battery and the host and can be monitoring from computer.
Battery Advantages :
Using highly temperature and high cycle life materials
Increased energy in given space
Parallel connection available for flexible system capacity extension
High operational reliability
Intelligent Battery Management System
Alarm function
Maintenance free throughout lifetime
Compatible with most of the available hybrid inverter
Convenient for installation
Abundant communication port
Highly operational reliability
real time monitoring
| Model | U-P48100-2/ U-P48150-2R/ U-P48200-2R |
| Norminal voltage | 48V |
| Norminal capacity | 100Ah/150Ah/200Ah |
| Continuousely discharge working current | 100A |
|
Charge Temperature
|
0℃-55℃
|
|
Discharge Temperature
|
-20℃-60℃
|
|
Charge Cut-off Voltage
|
52.5V±0.2V(Floating charge voltage)
|
|
Discharge Cut-off Voltage
|
38V±0.2V
|
|
Dimensions
|
D400*W442*H222mm/D520*W440*H265mm/D520*W440*H265mm
|
|
Weight
|
57Kg(APPROX)
|
|
Protocol(optional)
|
RS485/RS232
|
| SOC Light |
4*LED
|
|
Display Screen
|
LCD (optional) |
