Stationary Electric Hydraulic Dock Leveler Land Dock Ramp Truck Load Leveler
Stationary Electric Hydraulic CE Land Dock Ramp Truck Loading Leveler
Dock levelers and ramps are essential components of any loading and unloading operation at a warehouse or a shipping terminal. These devices are designed to ensure a smooth and safe transfer of goods from the dock to the truck bed and vice versa. There are various types of dock levelers and ramps available on the market, each with its unique features and benefits.
The hydraulic dock leveler is one of the most popular types of dock levelers. It operates by using hydraulic power to raise and lower the platform, which can be adjusted to match the height of the truck bed. This leveler provides a smooth and level transition for goods, reducing the risk of injury or damage to the goods during loading and unloading.
Specifications:
| Model No. | SDB-6 | SDB-8 | SDB-10 | SDB-12 | |
| Load Capacity (t) | 6 | 8 | 10 | 12 | |
| Platform Size (mm) | L2000/2500*W2000 | L2000/2500*W2000 | L2000/2500*W2000 | L2000/2500*W2000 | |
| Lip Width (mm) | 400 | 400 | 400 | 400 | |
| Travel Height (mm) | Updip | 300 | 300 | 300 | 300 |
| Downdip | 200 | 200 | 200 | 200 | |
| Motor Power (kw) | 0.75 | 0.75 | 0.75 | 0.75 | |
| Pit Size (mm) | 2080/2580*2040*600 | 2080/2580*2040*600 | 2080/2580*2040*600 | 2080/2580*2040*600 | |
| Electrical appliance | Delixi | Delixi | Delixi | Delixi | |
| 1X40’container Qty. | 20sets | 20sets | 20sets | 20sets | |
