300/500V, 450/750V H07rn-F 4mm2 6mm2 10mm2 16mm2 25mm2 35mm2 Copper Conductor Epr Insulated Welding Flexible Electric Rubber Cable
Price:
USD0.82-18.9/M
MOQ:
100M
Delivery Time:
7 to 10 days after receiving deposit
Brand:
ECHU
Product Description
Basic Info.
Model NO.
H07rn-F H05rn-f YCW
Conductor Material
Copper
Sheath Material
Rubber
Insulation Material
Rubber
Material Shape
Round Wire
Range of Application
Mine
Certification
ISO9001, CE, CCC
Brand
ECHU
Engineer No.
206
Plant No.
3 Plant with 12 Workshop
Standard
En BS VDE IEC
Transport Package
Roll Drum
Specification
1.5-300mm2
Trademark
ECHU
Origin
China
HS Code
8544492100
Production Capacity
50000km/Month
Product Description
300/500V, 450/750V H07rn-F 4mm2 6mm2 10mm2 16mm2 25mm2 35mm2 copper conductor rubber insulated welding flexible electric Rubber cable
1.H05RN-F H07RN-F Rubber Cable
This cable is primarily used in all kinds of electrical equipment, such as the mobile power of household appliances, electric machinery,
electrical equipment and tools, and it is also can be used in indoor or outdoor enviroment conditions.
Conductor: Stranded bare or tinned soft copper wire
Insulation: rubber
Sheath: rubber
2.Specification And Working Condition:
1)The rated voltage for YQ type is 300/300 V, YZ/YZW type(H05RN-F) is 300/500V,YC/YCW type(H07RN-F) is 450/750V.
2)The long-term working temperature allowed by conductor should be not more than 60 ° C.
3)W-type cable with climate resistance and oil resistance, suitable for outdoors or in contact with oil occasions.
4)ZR type cable has flame retardant properties, can be used for fire-retardant occasions.
3.Advantages Of H07RN-F:
The H07RN-F cable is used at medium mechanical stress in dry, wet and damp locations, as well in free air.
Also for fixed installation on plaster or machines. The cable is resistant to oil, UV-radiation and ozone.
Flexible
The H07RN-F is a flexible cable, ideal for mobile use.
This means that the cable can be used several times and can be applied for temporary purposes.
In addition, it is easy to handle and pliant making it easy and compact to store.
Its flexibility is also an advantage for small-spaced fixed installations as smaller bends can be made. Due to the flexibility of the cable,
it is easier and faster to install, which saves more time and reduces costs.
Oil Resistant
The H07RN-F is oil resistant which means the cable can withstand aggressive oil containing substances.
These substances will not affect the cable, the functionality of the cable will be maintained and the risk of irreparable damage is lower.
UV Resistant
Cables that are not UV resistant will be affected when they are exposed to direct sunlight.
The H07RN-F is UV resistant and can therefore be used above ground in the open air.
The outer sheath of the cable will not be harmed by the ultra-violet light which normally dries out a cable or causes cracks or bursts in the sheath.
This will preserve the functionality of the cable.
Flame Retardant
Cables used to be responsible for spreading fire. The H07RN-F is flame retardant.
This means that this cable is designed in a way that it will not spread fire.
Cables with these advantages are often used in buildings and at locations where people live, work and travel / move.
![300/500V, 450/750V H07rn-F 4mm2 6mm2 10mm2 16mm2 25mm2 35mm2 Copper Conductor Epr Insulated Welding Flexible Electric Rubber Cable]()
![300/500V, 450/750V H07rn-F 4mm2 6mm2 10mm2 16mm2 25mm2 35mm2 Copper Conductor Epr Insulated Welding Flexible Electric Rubber Cable]()
![300/500V, 450/750V H07rn-F 4mm2 6mm2 10mm2 16mm2 25mm2 35mm2 Copper Conductor Epr Insulated Welding Flexible Electric Rubber Cable]()
1.H05RN-F H07RN-F Rubber Cable
This cable is primarily used in all kinds of electrical equipment, such as the mobile power of household appliances, electric machinery,
electrical equipment and tools, and it is also can be used in indoor or outdoor enviroment conditions.
Conductor: Stranded bare or tinned soft copper wire
Insulation: rubber
Sheath: rubber
2.Specification And Working Condition:
1)The rated voltage for YQ type is 300/300 V, YZ/YZW type(H05RN-F) is 300/500V,YC/YCW type(H07RN-F) is 450/750V.
2)The long-term working temperature allowed by conductor should be not more than 60 ° C.
3)W-type cable with climate resistance and oil resistance, suitable for outdoors or in contact with oil occasions.
4)ZR type cable has flame retardant properties, can be used for fire-retardant occasions.
| Code | IEC | Description | Voltage Design | Cores |
| H05RR-F | 60245IEC 53(YZ)/YZ | Ordinary rubber sheathed cord | 300/500V | 2~6 |
| H05RN-F | 60245 IEC 57(YZW)/YZW | Ordinary polychloroprene or other equivalent synthetic elastomer sheathed cord |
300/500V | 2~6 |
| H07RN-F | 60245 IEC 66(YCW)/YC | Heavy polychloroprene or other equivalent synthetic elastomer sheathed flexible cable |
450/750V | 1~5, 3+1/3+2/4+1 |
| H01N2-D | 60245 IEC 81(YH) | Rubber sheathed arc-welding electrode cable | 100/100V | 10-120 |
| 60245 IEC 82(YHF) |
polychloroprene or other equivalent synthetic elastomer sheathed arc-welding electrode cable |
100/100V | 10-120 |
3.Advantages Of H07RN-F:
The H07RN-F cable is used at medium mechanical stress in dry, wet and damp locations, as well in free air.
Also for fixed installation on plaster or machines. The cable is resistant to oil, UV-radiation and ozone.
Flexible
The H07RN-F is a flexible cable, ideal for mobile use.
This means that the cable can be used several times and can be applied for temporary purposes.
In addition, it is easy to handle and pliant making it easy and compact to store.
Its flexibility is also an advantage for small-spaced fixed installations as smaller bends can be made. Due to the flexibility of the cable,
it is easier and faster to install, which saves more time and reduces costs.
Oil Resistant
The H07RN-F is oil resistant which means the cable can withstand aggressive oil containing substances.
These substances will not affect the cable, the functionality of the cable will be maintained and the risk of irreparable damage is lower.
UV Resistant
Cables that are not UV resistant will be affected when they are exposed to direct sunlight.
The H07RN-F is UV resistant and can therefore be used above ground in the open air.
The outer sheath of the cable will not be harmed by the ultra-violet light which normally dries out a cable or causes cracks or bursts in the sheath.
This will preserve the functionality of the cable.
Flame Retardant
Cables used to be responsible for spreading fire. The H07RN-F is flame retardant.
This means that this cable is designed in a way that it will not spread fire.
Cables with these advantages are often used in buildings and at locations where people live, work and travel / move.
------Our Feature------
- Imported equipment with experienced technical team
- Complete certification system
Qifan Cable have gotten ISO 9001, ISO 14001, ISO45001 Plant passed TUV, VDE, UL, CE, SAA, BS etc. certificate. - Perfect Production system
ECHU Cable products cover LV power cable , robot cable, drag chain cable, EV charging cable, UL cables, submarine cable, control cable, instrumentation cable, building wire, flexible rubber cable, fire rated cable, renewable cable, solar cable, industrial cable, Lan cable etc. - Perfect Sales service system
ECHU Cable can offer the OEM/ODM service, Multiple products, Skilled Export sale engineer team, Reasonable price, Reliable quality, Friendly service. ECHU is always your best choice.
