Water Faucet UVC LED Disinfection Sterilization Modules 270nm 275nm 280nm
Price:
Negotiation
MOQ:
3
Delivery Time:
100days
Brand:
Tianhui
Product Description
TH-UVC-SW01 270NM 275NM 280NM Commercial Water Dispenser Water Outlet Faucet UVC LED Disinfection Sterilization Modules
Lead_Time:
1 - 10(pieces):15(days),>10(pieces):Negotiable(days)
Shipping:
Express Sea freight · Land freight · Air freight
Place Of Origin:
Guangdong, China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
Brand:
Tianhui
Lead Time:
100days
MOQ:
1000
Model:
TH-UVC-SW01
UV-C LED Flowing Water Sterilization Module
TH-UVC-SW01
Description
TH-UVC-SW01 is a UVC LED flowing water disinfection module(Faucet) applied for the water outlet of commercial water dispenser with self luminous effect.
Its UVC LED light source's wavelength range 270~280nm has excellent and efficient sterilization effect. The internal chamber is designed by high UVC refelectivity to increase the utilization of UV light and improve the sterilization effect.
In order to ensure the safety of drinking water, there is a special construction design of this UVC module which is able to prevent the plastic aging in maximum extent where the parts contact with water directly.
Feature
• Reference standard: QB/T 4827- 2015
• UVC LED (270-280nm)
• Environmental friendly
• UVC LED (270-280nm)
• Gorgeous Lighting
- Built-in visible LED matched with transparent shell to enhance the awareness of users.
• Environmental friendly
- Compliant with RoHS and Reach
Application
• Commercial Water Dispenser
• Drinking Machine
• Under the Kitchen Water Purifier
• Tea Bar Machine
|
Item
|
Specifications
|
Note
|
|
Part Number
|
TH-UVC-SW01
|
|
|
Connector of Water Inlet
|
G1/2 External Thread
|
|
|
Rated Voltage
|
DC 12V
|
|
|
UVC Radiant Power
|
≥90mW
|
|
|
UVC Wavelength
|
270~280nm
|
|
|
Sterilization Rate
|
≥99.9% (Escherichia Coli)
|
Under 2L/MIN
|
|
Input Current
|
340mA
|
|
|
Input Power
|
4W
|
|
|
Waterproof Level of Outer Shell
|
IP60
|
|
|
Appropriate Water Pressure
|
≤0.2MPa
|
Unconfined Module
|
|
Cables
|
UL2464#24AWG-2C
|
|
|
Connector
|
Customization
|
Customizable
|
|
LED Lifespan
|
10,000-25,000 hours
|
According to the LED model
|
|
Insulation and Voltage Resistance
|
DC500 V,1min@10mA, leakage current
|
|
|
|
Φ50(Diameter)*79(Body Length)
|
|
|
Net Weight
|
200±5g
|
|
|
Working Water Flow Rate
|
1.0~2.5L/min
|
The sterilization effect will be decreased when water flow rate is beyond 2L/MIN.
|
|
Appropriate Water Temperature
|
4℃-45℃
|
|
|
Storage Temperature
|
-40℃-85℃
|
|
Remarks
• The peak wavelength (λp) measurement tolerance is ±3nm.
• The measurement tolerance of radiant flux (Φe) is ±10%.
• The measurement tolerance of forward voltage (Vf) is ±3%.
