TiO2 Ceramic Powder Thermal Spray Powder Metco 102
TiO2 Ceramic Powder Thermal Spray Powder Metco 102 The Production Of Dry Cell Batteries Sliding Wear
TiO2 power is a titania based power containing more than 99% titania that is used for different kinds of coating,such as wear resistant coating, dry lubricious coating and so on. The power has low electrical resistivity and favorable sputtering properties.In addition,coatings with relatively higher porosity can be obtained with this power.
Equivalent:Metco 102,FST C-407,Amperit 782
Chemical Composition
| TiO2 | Al2O3 | Fe2O3 | SiO2 | All others | X-factor |
| Balance | ＜0.1% | ＜0.1% | ＜0.1% | ＜0.5% | 1.7% |
Physical Properties
| Classification | Oxide ceramic, alumina based |
| Chemistry | TiO2 99.0 + |
| Manufacture | Fused and crushed |
| Morphology | Angular /blocky |
| Purpose | Wear and corrosion resistance, decorative,electrical conductance |
| Service Temperature | 1843°C (3350°F) |
| Melting Point | ≤ 540 °C (1000 °F) |
| Process | Atmospheric plasma spray orcombustion powder Thermospray™ |
Packing Details
| Granularity | -15 +45μm other size can be customized |
| Packing | 5 kg/bottle 4 bottles/box |
Typical uses and Applications
■ Electrically conductive coatings for sputter targets for use in thin film processes to produce thin titania films on architectural and automotive glass
■ Sliding wear resistance for automotive applications such as cylinder bore liners
■ Oxygen sensors
■ Decorative coatings having a dark gray color
■ Mandrels for the production of dry cell batteries
■ Biomedical implants
■ Filter elements and membranes
Type We Could Offer
Thermal spray powder-Oxide ceramic
| WL TYPE | Metco | Size |
| WL-Al2O3 | Metco 105SFP | Customized |
| WL-Al2O3 13TiO2 | Metco 6221 | Customized |
| WL-Al2O3 40TiO2 | Metco 131VF | Customized |
| WL-Cr2O3 | Metco 106NS | Customized |
| WL-Cr2O3 5SiO2 3TiO2 | Metco 136F | Customized |
| WL-TiO2 | Metco 6231A, 6232B, 6233C | Customized |
| WL-TiO2 45CrO3 | Metco 111 | Customized |
| WL-ZrO2 8Y2O3 | Metco 6608 | Customized |
| WL-ZrO2 24MgO | Metco 210 | Customized |
