2V Deep Cycle Opzv Tubular Gel Battery 1000ah 2000ah 3000ah M8 Terminal

Price Negotiable
Price: Negotiable
MOQ: Negotiable
Delivery Time: 7-15working days
Brand: KVOU
Product Description

Pinergy Gel Battery Opzv 2V 1000ah 2000ah 3000ah for Solar Energy Storage System



Describe

Tubular plate design enhances battery performance
Tubular plate design makes long battery life
Relatively rich electrolyte makes high-low temperature superior performance
Long cycle life,excellent deep cycle discharge ability*Excellent charge acceptance ability
Precision sealing technology



Usually makes lithium-ion batteries the long-term economical choice. High-performance attributes further underscore the value of lithium-ion batteries, including zero negative memory effect, high power density to weight ratio, and a near-flat power curve at the end of charge.

The safety problems of lithium batteries in the past are no longer a problem for modern models, and they have passed extrusion and puncture tests many times without catching fire. Additionally, these lithium batteries do not contain heavy metals or hazardous substances, so there is minimal risk to human health and the environment if damaged.

In addition, the built-in BMS monitoring management chip can prevent the battery pack from overcharging, overdischarging, overheating or short circuit. This standard technical feature ensures that internal operational safety is separated from the risk of external damage.

As a derivative of lithium-ion batteries, lithium iron phosphate or LiFePO4 batteries offer special advantages compared to the popular lithium cobalt oxide chemistry range. These positives include a longer shelf life, often holding the same energy density as a LiCoO2 chemistry battery after one year in storage. LiFePO4 batteries are also renowned for their safety and low toxicity, being both thermally and chemically stable and 100% cobalt & nickel free, which additionally reduces the price of these batteries compared to other Li-Ion chemistries, as these are rare and expensive metals.



Nominal Voltage
2V
Nominal Capacity
500Ah
Design life
20 years
Terminal
M8
Approx. Weight
Approx 38.1kg (84.1lbs)
Container Material
ABS

Rated Capacity
500 AH
10Hour Rate
50A to 1.80V
378AH
3Hour Rate
126A to 1.80V
278AH
1Hour Rate
278A to 1.75V
Internal resistance
Full charged at 25°C, 0.62 mΩ
Max. Discharge Current
2400A(5S)
Operating Temperature
Discharge: -20 ~50℃(-20~ 122°F)
Charge : -20 ~50℃(-4~ 122°F)
Storage: -20 ~50℃(-4~ 122°F)
Charge Method (25 °C)
Charge current: Max. 60.0A;Recom.30.0A
Float Charge:2.23-2.27V, recom.2.25V(-3mV/ °C)
Equalize charge:2.30-2.35V, recom.2.35V(-4mV/
Cycle charge:2.40-2.50V, recom.2.40V(-5mV/ °C)
Self discharge
3% of capacity declined per month at 25°C



FQA:

1. Q:Which shipping method you usually take?

A:Train/Sea DDP, Express, We can also ship with your own shipping agent.



2. Q:How do I know whether you've shipped my order or not?
A:Tracking No.will be offered as soon as your order be shipped out. Before that,our sales will be there to check the packing status, photo of the order and let you know the detail shipment information.



3. Q:Can I have a sample order?
A:Yes, we welcome sample order to test and check quality.



4. Q:What about the lead time?
A:Sample needs 3 days, mass production time needs 5-7 weeks, it depends on order quantity.
