IN STOCK Winston 3.2V Lifepo4 200ah For Hybrid Car Ebike And Power Bank Battery
IN STOCK Winston 3.2V Lifepo4 200ah for hybrid car ebike and power bank battery
Characteristics:
1.LYP type of battery is ideally used as a mobile power source and energy storage device.
2. This type of battery has excellent safety performance and cycle life.
3. When the battery case temperature is below 85 degrees, this type of batteries can accept a fast charge and discharge under 3CA current.
Advantages
1.Safe and Reliable
High level of safety, never explode,can be over charged or discharged, need BMS
2. Energy Density
High energy density, now density is 3 times of lead-acid battery.
3. Long Life
Can be charged and discharged repeatedly over 7000 times, life can reach up more than 20 years.
The most cost effective in the lithium ion battery industry.
4. Green and Environmental Friendly
Manufacturing, using and recycling are all friendly to the environment.
5. Mature Technology
Automatic production procedure R&D all by ourselves, in line with lATF 16949, and past CE tested.
6. Reasonable Price
Parameters
| Model | WB-L YP40AHA | WB-L YP60AHA | WB-L YP90AHA | WB-L YP100AHA (A) | |
| Nominal Capacity | 40AH | 60AH | 90AH | 100AH | |
| Cycle Life | ≧5000 times | ≧5000 times | ≧5000 times | ≧5000 times | |
| Warranty 2 Years 2 Years 2 Years 2 Years | |||||
| Weight | 1.6kg+50g | 2.3kg+50g | 3.0kg+100g | 3.3kg+100g | |
| Dimension | 115x47 x 183 (mm) | 114x61 x 203 (mm) | 143 x 61 x218 (mm) | 143 x 67 x218 (mm) | |
| Model | WB-L YP100AHA (B) | WB-L YP160AHA | WB-L YP130AHA | ||
| Nominal Capacity 100AH 1 60AH 130AH | |||||
| Cycle Life | ≧5000 times | ≧5000 times | ≧ 5000 times | ||
| Warranty 2 Years 2 Years 2 Years | |||||
| Weight | 3.6kg±100g | 5.7kg±150g | 5.2kg±100g | ||
| Dimension 179 x 62 x 218 (mm) 209 x 65 x278 (mm) 360 x 55 x 177 (mm) | |||||
| 一 | |||||
| Model | WB_L YP200AHA | WB-LYP260AHA | WB-L YP300AHA | ||
| Nominal Capacity | 200AH | 260AH | 300AH | ||
| Cycle Life | ≧ 5000 times | ≧5000 times | ≧5000 times | ||
| Warranty | 2 Years | ||||
| Weight | 7.9kg±200g | 8.7kg±200g | 9.7kg±250g | ||
| Dimension | 361 x 55.2 x256 (mm) | 361 x 55.5x 283 (mm) | 362 X 55.5x 306 (mm) | ||
| Model | WBL YP400AHA | WB-LYP700AHA | WB-L YP1000AHA | ||
| Nominal Capacity | 400AH | 21kg±300g | 1000AH | ||
| Cycle Life | ≧ 5000 times | ≧ 5000 times | ≧5000 times | ||
| Warranty | 2 Years | ||||
| Weight | 13.5kg±250g | 8.7kg±200g | 41kg±500g | ||
Case examples:
1. In the United States, it is used for mobile power supply, container trucks, school buses and concept cars.
2. In France, Citrine has been used in destructive tests on electric mail vehicles.
3. In Germany,it is used for routine submarine test, pure electric small car and trucks.
4. In Japan, it is used in two-seater electric cars.
5. In the United Kingdom, it is widely used in the electric vehicle inductry,equipped with pure electric bus, medium truck,refrigerated small truck and so on.
6. In the five Nordic countries, it is applied to pure electric vehicles.
Finland actually uses it at minus50 degrees, which performs good.
7. In Italy, it is applied to two-seater electric cars, pure electricminibuses,vans,small and medium trucks, etc.
8. In Dubai, tourist submarines are used as the main power source of tourist submarines.
