Storage Battery 12V 33Ah Lead Acid GEL Battery For Solar Power System

Price Negotiable
Price: Negotiable
MOQ: Negotiable
Delivery Time: 7-15working days
Brand: KVOU
Product Description

High Quality Storage Battery 12V 33Ah Lead Acid GEL Battery For Solar Power System

Product Paramenters
NominalVoltage
12V
Nominal Capacity(10HR)
33AH
Dimension
Length
195 ± 2mm (7.76 inches)
Width
130 ± 2mm (5.12inches)
Container Height
155 ± 2mm (6.10 inches)
Total Height (withTerminal)
168 ± 2mm (6.61inches)
Approx Weight
Approx 9.75 kg (21.5lbs)
Terminal
T6 / T12
Container Material
ABS
Rated Capacity
34.5 AH/1.976A
(20hr ,1.80V/cell,25℃/77℉)
32.7 AH/3.8A
(10hr,1.80V/cell,25℃/77℉)
29.7 AH/6.55A
(5hr,1.75V/cell,25℃/77℉)
23.2 AH/9.89A
(3hr,1.75V/cell,25℃/77℉)
Max. Discharge Current
360A (5s)
Internal Resistance
Approx 10mΩ
Operating Temp.Range
Discharge : -15~50℃ (5~122℉)
Charge : 0~40℃ (32~104℉)
Storage : -15~40℃ (5~104℉)
Nominal Operating Temp. Range
25 ± 3℃ (77 ± 5℉ )
Cycle Use
Initial Charging Current less than 11.4 A.Voltage
14.4V~15.0V at 25℃(77℉)Temp. Coefficient -30mV/℃
Standby Use
No limit on Initial Charging Current Voltage
13.5V~13.8V at 25℃(77℉)Temp. Coefficient -20mV/℃
Capacity affectedby Temperature
40℃ (104 ℉) 103%
25℃ ( 77 ℉ ) 100%
0℃( 32℉ ) 86%
Self Discharge
Techfine batteries may be stored for up to 6months at 25℃(77℉) and battery should be recharge before use . For higher temperatures
the time interval will be shorter.



FAQ:



Q: What causes a battery to drain?
A:“Electrical devices or lights left running, a defective charging system or alternator, and extreme weather are some common reasons but maybe it's just time to get a new battery.”



Q: Can a battery stop working after 2 years?
A: Batteries gradually deteriorate until they can no longer provide enough power to start an engine. This wear time could take three to five years and a vehicle's usage pattern is one factor contributing to the rate at which a battery will age.


Q: How many batteries are needed for 10kW?
A: In conclusion, a 10kW solar system typically requires a battery bank with a capacity of 20-30kWh, which can require between 100-150 batteries with a capacity of 200Ah each. However, it is important to consult with a professional to determine the exact number of batteries required for your specific solar power system.



Q: How long will a 5kw battery last?
A: Approximately ten hours. Typically, a 5kWh solar battery can last approximately ten hours when you're only running a few appliances, such as your TV, fridge, and even a few lights. However, it will drain quickly if you add the use of heavy-duty appliances, such as air conditioners.
