Industry Ro Membrane And Housing Victaulic Coupling Housing Cartridge Filter
8 Inch Industry SS Membrane Housing Victaulic Coupling Inlet Connection
Technical Parameters of membrane housing
8’’ Membrane Housing-VC-300PSI/600PSI-For Industry
Side port, with qty. of 2~8 pcs
SS retaining ring closure
Max working pressure: 300PSI/600PSI
Max working temperature: 90 ℃
Housing Material: SS304/316L
End cap material: SS 304/316L
Adapter: SS304/316L
O-ring material: EPDM, with NSF certificate
Finish: Mechanical polishing (320 mesh, Ra<0.6)
F/C port:Victaulic
Permeate port: NPT/BSP female thread
Model: for 8040 , from 1~6 element
Parameter List
| Model | L(mm) | L1(mm) | ID(mm) | A(inch) | B(inch) |
| JD-8040-1 | 1359 | 1119 | 203 | 1.5-3" | 1.5" |
| JD-8040-2 | 2375 | 2135 | 203 | 1.5-3" | 1.5" |
| JD-8040-3 | 3391 | 3151 | 203 | 1.5-3" | 1.5" |
| JD-8040-4 | 4407 | 4167 | 203 | 1.5-3" | 1.5" |
| JD-8040-5 | 5423 | 5183 | 203 | 1.5-3" | 1.5" |
| JD-8040-6 | 6439 | 6199 | 203 | 1.5-3" | 1.5" |
Porudct Picture
Package& shipment
| size | package type | suggested shipment | delivery time |
| 4inch | carton box with protection | LCL/FCL/AIR SHIPPING | 10-20DAYS |
| 8inch | carton box with protection | LCL/FCL/AIR SHIPPING | 10-20DAYS |
| special long models | carton box with protection | FCL | 10-20DAYS |
