CBB65 450V 20UF Round Type Capacitor S2 ROHS Air Compressor 3000 Hours C-Class
CBB65 450V 20UF Round Type Capacitor S2 ROHS Air Compressor 3000 Hours C-Class
CBB65 Motor Run Capacitors (Round-Shaped, Single Capacitance Value or daul Capacitance Value).CBB65 Motor Run Capacitors feature a low-loss, self-healing Metalized Polypropylene Film dielectric system, which are castor oil-filled.The motor run capacitors with Single capacitance value are offered in voltages ranging from 240 through 660 VAC and with Single capacitance range of 0.5 to 120 microfarads.
Applications
Widely used in the starting and operation of motors (compressors) of air conditioners, washing machines, dishwashers, fans and other electrical equipment.
Basic Info.(Techical Parameters)
Rated frequency | 50/60Hz | |
Rated Voltage | 450V.AC | |
Capacitance Range | 20UF | |
Capacitance tolerance | ±5% | |
Withstand voltage test | 2Un 2S | |
Operating temperature range | -40℃~+85℃(-40/85/21) | |
| Rated Voltage | 250V.AC-600V.AC | |
| Capacitance Range | 3uF~100uF | |
| Capacitance tolerance | ±5% (J),±10%(K) | |
| Tangent of loss angle(20℃) | ≤0.0010(at 100Hz) | |
| Dissipation factor | ≤0.2%(100Hz) | |
| Climatic cctegory | -40°C~105°C | |
| Operation life time | A Class(30000h)B Class(10000h) | |
| Withstand voltage | Withstand voltage between terminals | UL:1.5Un/2sOthers:2.0Un/2S |
| WVithstand voltage terminals to case | ≥2000VAC/2S | |
| Apply certificate | CQC,VDE,UL,CUL,CSA | |
| Operation temperature range | -40℃~+105℃(40170121 40/85121 40/105/21) |
| Rated Voltage | 250V.AC-600V.AC |
| Capacitance Range | 3uF~120uF |
| Capacitance tolerance | ±5% (J),±10%(K) |
| Tangent of loss angle(20℃) | ≤0.0010(at 100Hz) |
| Insulation resistance | Rc>5000s(100V.DC 60s) |
| Flammability | UL94V-0 |
| Operation life time | 3000H(C Class)at 70℃/10000H(B Class) at 85℃ /30000H(A Class)at 85℃ |
| Withstand voltage | 2.0Un (VAC)/60s(CQC, VDE, TUV) |
| 1.5Un (VAC)/60s (UL) | |
| 2.0Un+1000(VAC)/60s(≥2000VAC) | |
| Class of safety protection | UL VDE CQC(SO) / UL TUV CQC(S3) |
