Air Conditioner Fan Capacitor CBB60 450V 3.5UF Grey Plastic Shell 50 / 60HZ RoHS
Air Conditioner Fan Capacitor CBB60 450V 3.5UF Grey Plastic Shell 50 / 60HZ RoHS
The CBB60 450V 3.5UF Grey Plastic Shell Capacitor is specifically engineered for use in air conditioner fan systems. With a capacitance rating of 3.5 microfarads and a voltage tolerance of 450V, it ensures reliable performance in a variety of air conditioning setups. Encased in a durable grey plastic shell, this capacitor is designed to withstand the rigors of prolonged operation and environmental factors. Operating at both 50Hz and 60Hz frequencies, it meets RoHS compliance standards, guaranteeing its environmental safety. This capacitor facilitates smooth and efficient operation of air conditioner fans, contributing to the overall performance and longevity of the cooling system.
Applications
It has the advantages of high voltage resistance, strong ability to withstand large current impact and high safety.Used for fans, air conditioners, water pumps, etc.
Basic Info.(Techical Parameters)
|
Rated frequency |
50/60Hz |
|
|
Rated Voltage |
450V.AC |
|
|
Capacitance Range |
3.0UF |
|
|
Capacitance tolerance |
±5% |
|
|
Withstand voltage test |
2.0Un 2S | |
|
Flammability |
UL94V-0 |
|
|
Operating temperature range |
-40~+85℃(40/85/21) | |
| Operation temperature range | -40℃~+105℃(40170121 40/85121 40/105/21) |
| Rated Voltage | 250V.AC-600V.AC |
| Capacitance Range | 3uF~120uF |
| Capacitance tolerance | ±5% (J),±10%(K) |
| Tangent of loss angle(20℃) | ≤0.0010(at 100Hz) |
| Insulation resistance | Rc>5000s(100V.DC 60s) |
| Flammability | UL94V-0 |
| Operation life time | 3000H(C Class)at 70℃/10000H(B Class) at 85℃ /30000H(A Class)at 85℃ |
| Withstand voltage | 2.0Un (VAC)/60s(CQC, VDE, TUV) |
| 1.5Un (VAC)/60s (UL) | |
| 2.0Un+1000(VAC)/60s(≥2000VAC) | |
| Class of safety protection | UL VDE CQC(SO) / UL TUV CQC(S3) |
