High Efficiency 50L / Min Silent Rocking Piston Vacuum Pump Medical Suction
Price:
Negotiable
MOQ:
100 PCS
Delivery Time:
15-30 days
Brand:
XWD
Product Description
Complete solution leader in oilless air pump field
* Oilless operation
* Permanently lubricated bearings
* High performance piston seal
* Die-cast aluminum components
* Thin wall, hard coated aluminum cylinder
* Dynamically balanced
* Twin headed rock piston
* RoHS compliant
* Safety ETL certificated
| Model Number | SMV-50 | ||
| Performance Data | |||
| Head configuration | Pressure parallel flow | ||
| Nominal voltage | 220V/50HZ | ||
| Max. Current | 0.75A | ||
| Max.POWER | 160W | ||
| Max. Flow | 50L/MIN | ||
| Max. Vacuum | -90Kpa | ||
| Speed at rated load | 1400RPM | ||
| Noise | ＜52dB | ||
| Max.Pressure restart | 0PSI | ||
| Electrical Data | |||
| Motor insulation class | B | ||
| Thermal switch[Open temperature] | Thermally protected(145°C) | ||
| Line lead wire color,gauge | Brown(hot),blue(neutral),18AWG | ||
| Capacitor lead wire color,gauge | Black,black,18 AWG | ||
| General Data | |||
| Operating ambient air temperature | 50° to 104°F(10° to 40°C) | ||
| Safety certification | ETL | ||
| Dimension(LXWXH) | 168X99X150mm | ||
| Net weight | 3.5KG | ||
| Application | Medical suctions, lab,vacuum packaing etc. | ||
