2KA Surge Capability Gas Discharge Tube SC1812-350CSMD Square Outline GDT
Price:
Negotiable
MOQ:
2500PCS
Delivery Time:
5-8 work days
Brand:
SOCAY
Product Description
2KA Surge Capability Gas Discharge Tube (GDT) SC1812-350CSMD, Square Outline
DATASHEET: SC1812_v2106.1.pdf
| Part Number | DC Spark-over Voltage | Maximum Impulse Spark-over Voltage | Minimum Insulation Resistance | Maximum Capacitance | Arc Voltage |
Nominal Impulse Discharge Current |
|
| @100V/S | @100V/μs | @1KV/μs | @1MHz | @1A |
@8/20μs ±5 times |
||
| SC1812-75CSMD | 75V±30% | ＜600V | ＜700V | 1 GΩ (at 50V DC) | ＜1.0pF | ~15V | 2 KA |
| SC1812-90CSMD | 90V±20% | ＜600V | ＜700V | 1 GΩ (at 50V DC) | ＜1.0pF | ~15V | 2 KA |
| SC1812-150CSMD | 150V±20% | ＜600V | ＜700V | 1 GΩ (at 50V DC) | ＜1.0pF | ~15V | 2 KA |
| SC1812-200CSMD | 200V±20% | ＜600V | ＜750V | 1 GΩ (at 100V DC) | ＜1.0pF | ~15V | 2 KA |
| SC1812-230CSMD | 230V±20% | ＜600V | ＜750V | 1 GΩ (at 100V DC) | ＜1.0pF | ~15V | 2 KA |
| SC1812-300CSMD | 300V±20% | ＜800V | ＜900V | 1 GΩ (at 100V DC) | ＜1.0pF | ~15V | 2 KA |
| SC1812-350CSMD | 350V±20% | ＜800V | ＜900V | 1 GΩ (at 100V DC) | ＜1.0pF | ~15V | 2 KA |
|
Notes:
|
|||||||
Descriptions:
Gas discharge tube is one of the most widely used lightning protection devices, whether it is AC, current power supply lightning protection or various signals lightning protection, play a very good protection role. Its main characteristics are: large through flow, small electrode capacitance, high insulation resistance, breakdown voltage optional range, but slow reaction speed (high residual voltage).
Applications:
- driving power supply,
- switching power supply,
- power module, isolator, i
- nverter, medical equipment,
- 485 converter,
- communication products (optical terminal machine,
- MODEL, communication base station),
- stabilizer, security products, lightning arrester.
