59U Pump John Crane Seal
OEM/ODM 58U/59U Pump John Crane Seal Sewage Pumps Reactors Chemical Pumps Single Face Mechanical Seal
Performance Capabilities:
|
Temperature
|
-40ºC to 150ºC, dependent on the elastomer
|
|
Pressure
|
≤1.7MPa |
|
Speed
|
≤25m/s |
|
End play/axial float allowance
|
±0.1mm
|
|
Size
|
14-100MM
|
|
Brand
|
BE
|
|
Face
|
Carbon, SiC, TC
|
|
Seat
|
Ceramic, SiC, TC
|
|
Elastomer
|
NBR, EPDM, etc.
|
|
Spring
|
SS304, SS316
|
|
Metal parts
|
SS304, SS316
|
|
Idividual Packing
|
Using foam and plastic paper wrapped, then put one piece of seal in one box,finally put in standard export carton.
|
| Seal Size d | D3 | D2 | D1 | L1 | L2 | L3 |
| 14 | 24.0 | 21.0 | 25.0 | 23.0 | 12.0 | 18.5 |
| 16 | 26.0 | 23.0 | 27.0 | 23.0 | 12.0 | 18.5 |
| 18 | 32.0 | 27.0 | 33.0 | 24.0 | 13.5 | 20.5 |
| 20 | 34.0 | 29.0 | 35.0 | 24.0 | 13.5 | 20.5 |
| 22 | 36.0 | 31.0 | 37.0 | 24.0 | 13.5 | 20.5 |
| 24 | 38.0 | 33.0 | 39.0 | 26.5 | 13.5 | 20.3 |
| 25 | 39.0 | 34.0 | 40.0 | 27.0 | 13.0 | 20.0 |
| 28 | 42.0 | 37.0 | 43.0 | 30.0 | 12.5 | 19.5 |
| 30 | 44.0 | 39.0 | 45.0 | 30.5 | 12.0 | 19.0 |
| 32 | 46.0 | 42.0 | 48.0 | 30.5 | 12.0 | 19.0 |
| 33 | 47.0 | 42.0 | 48.0 | 30.5 | 12.0 | 19.0 |
| 35 | 49.0 | 44.0 | 50.0 | 30.5 | 12.0 | 19.0 |
| 38 | 54.0 | 49.0 | 56.0 | 32.0 | 13.0 | 20.0 |
| 40 | 56.0 | 51.0 | 58.0 | 32.0 | 13.0 | 20.0 |
| 43 | 59.0 | 54.0 | 61.0 | 32.0 | 13.0 | 20.0 |
| 45 | 61.0 | 56.0 | 63.0 | 32.0 | 13.0 | 20.0 |
| 48 | 64.0 | 59.0 | 65.0 | 32.0 | 13.0 | 20.0 |
| 50 | 66.0 | 62.0 | 70.0 | 34.0 | 13.5 | 20.5 |
| 53 | 69.0 | 65.0 | 73.0 | 34.0 | 13.5 | 20.5 |
| 55 | 71.0 | 67.0 | 75.0 | 34.0 | 13.5 | 20.5 |
| 58 | 78.0 | 70.0 | 78.0 | 39.0 | 13.5 | 20.5 |
| 60 | 80.0 | 72.0 | 80.0 | 39.0 | 13.5 | 20.5 |
| 63 | 83.0 | 75.0 | 83.0 | 39.0 | 13.5 | 20.5 |
| 65 | 85.0 | 77.0 | 85.0 | 39.0 | 13.5 | 20.5 |
| 68 | 88.0 | 81.0 | 90.0 | 39.0 | 13.5 | 20.5 |
| 70 | 90.0 | 83.0 | 92.0 | 45.5 | 14.5 | 21.5 |
| 75 | 99.0 | 88.0 | 97.0 | 45.5 | 14.5 | 21.5 |
| 80 | 104.0 | 95.0 | 105.0 | 45.0 | 15.0 | 22.0 |
| 85 | 109.0 | 100.0 | 110.0 | 45.0 | 15.0 | 22.0 |
| 90 | 114.0 | 105.0 | 115.0 | 50.0 | 15.0 | 22.0 |
| 95 | 119.0 | 110.0 | 120.0 | 50.0 | 15.0 | 22.0 |
| 100 | 124.0 | 115.0 | 125.0 | 50.0 | 15.0 | 22.0 |
Operational Conditions:
- John Crane seal 58U is structural simple and reliable. It has a wide application scope.
58U, mechanical seal is suitable for clean water pumps, sewage pumps, submerged pumps, process pumps, etc.
This also can provide important material certifications available. Salvador, Senior, Sandy. - Temperature: -30ºC to 200ºC, depend on o-ring material
- Pressure: Up to 1.7 bar
- Speed: Up to 25 m/s
- End play/axial float allowance ±1mm
- Materials:
- Stationary Ring: Ceramic, Silicon Carbide, TC
- Rotary Ring: Carbon, Silicon Carbide
- Secondary Seal: NBR, EPDM, PTFE
- Spring and Metal Parts: SUS304/SUS316
- 3. Seat Type:
- 4. Applications: Clean water, sewage water, oil and other moderately corrosive fluids
FAQ
Question 1: Are you a factory or a trading company?
Answer: We are a factory manufacturing mechanical seals. We have regular models in stock and customized products are also available. Please feel free to contact us if you need any.
Question 2: What is the minimum order quantity for each order?
Answer: For products of regular models, the minimum order quantity is at least ten. We welcome you to test the quality of our products and our services through small orders and look forward to long-term cooperation with you next.
Question 3: How can I pay my order?
Answer: We accept T/T, Paypal, D/P, Western Union, Money Gram to pay.
Question 4: Can I try to get a Sample before the order?
Answer: Sure. But our company can not provides you with samples for free, and you also have to pay for the international delivery (freight collect payment)
