3000kg FR4WD30 All Terrain Forklift 4X4 Off Road Forklift Yanmar Engine 3ton
3000kg FR4WD30 3ton all terrain forklift 4X4 Japanese Yanmar engine container mast
Main information:
4X4 wheel drived
Load capacity: 500mm
Engine: Japanese Yanmar 4TNE98 engine
Transmission: Automatic
Mast type: Duplex mast 3m lifting height
Tires: Pneumatic
Fork: 1220mm
Attachments: Side shift
YEAWEY Rough Terrain Forklift is built with an emphasis on performance,reliability and high tech design. Compact size, with rounded body design,allows better forward, side & rear visibility for the operator.
Short wheelbase provides tight turning radius to maneuver in congested or limited space operating areas.
Specifically designed for the construction,mining, forestry lumber & building industry,these forklift trucks have high under clearance,tremendous mobility and stability on rouih terrain with or without load.
Rugged designed one piece frame is robotic welded for maximum rigidity, superior quality and lone term endurance to meet the most demanding operating conditions.
Two-Wheel Drive System
Yeawey rough terrain forklift is a tough, compact forklift with a two-wheel drive system.
The forklift is based on conventional forklift, but its rough terrain performance is excellent.
Transmission with Differential Lock
Power shift transmission with torque converter has two pedal inching, brake control and full reversal allowing faster cycle times.
The differential is specifically designed for rough terrain and features automatic differential lock, providing ultimate traction during inclement weather conditions and rough operating surfaces.
High Ground Clearance
2.5T-3T rough terrain forklift body min. ground clearance is 250mm; 3.5T-4T rough terrain forklift body min. ground clearance is 285mm;High ground clearance offers greater maneuverability and keeps the machine moving in the roughest of applications.
High Quality & Durable tires
Yeawey rough terrain forklift front tires are a special heavy truck tire with a wide footprint giving it greater stability and lift capacity in rough work environments.
Large Opening Angle
Enlarged internal space is convenient for engine and transmission box maintenance.
Increased hood opening angle makes maintenance convenient.
Adjustable Steering Wheel
Provide convenience and can customize to the operator's desired position.
Warranty:
The warranty period is 24 months from on board date or 2000 working hours whichever comes first.
During warranty, we offer air delivery of the spare parts within 2 working days.Besides that, we have experienced engineers to check the problems and maintenance.
Delivery time:
As a factory, we can offer fast products delivery, standard forklift is 7 working days, Forklift with options is 10-20 working days.
Should you have any questions pls feel free to let us know.
| Model | FR4WD30 | ||
| Power | Diesel | ||
| Load capacity | kg | 3000 | |
| Load center | mm | 500 | |
| Lift height | mm | 3000 | |
| Fork size | mm | 45x125x1370 | |
| Mast tilting angle front/rear | Deg | 6/12 | |
| Min. turning radius | mm | 3960 | |
| Groud clearance | mm | 250 | |
| Overhead guard height | mm | 2450 | |
| Travel speed(unladen) | km/h | 30 | |
| Lifting speed(laden/unladen) | mm/s | 450/550 | |
| Lowing speed(laden/unladen) | mm/s | ≤600/≥300 | |
| Max. Gradeability (Laden) | % | 25 | |
| Length | With fork | mm | 4160 |
| Without fork | mm | 3090 | |
| Width | mm | 1600 | |
| Mast extended height | mm | 4350 | |
| Mast lowered height | mm | 2235 | |
| Tires | Front | 12-16.5-10PR | |
| Rear | 12-16.5-10PR | ||
| Wheel base | mm | 1840 | |
| Tread front/rear | mm | 1250/1320 | |
| Service weight | Kg | 4900 | |
| Battery | V/Ah | 12/80(2个) | |
| Engine | Model | Japanese Yanmar engine | |
| Reated power | kw/r.p.m | 42/2400 | |
| Rated torque | Nm/r.p.m | 185/1600-1800 | |
| Cylinders | 4 | ||
| Displacement | L | 2.543 | |
| Fuel tank capacity | L | 80 | |
| Transmission | Automatic | ||
| Shift(front/rear) | 2/2 | ||
