China 2500Kgs CPD25 2.5 Ton Electric Forklift AC Motor Lead Acid Battery Forklift for sale

2500Kgs CPD25 2.5 Ton Electric Forklift AC Motor Lead Acid Battery Forklift

Name: 2500Kgs CPD25 2.5 Ton Electric Forklift AC Motor Lead Acid Battery Forklift
Brand: Qingdao Yeaweyda Machinery Co., Ltd

Price Negotiable

Price: 4000-5000 usd

MOQ: 1 unit

Delivery Time: 15-20 working days

Brand: YEAWEY

Product Description

2500 kgs CPD25 2.5 Ton electric forklift lead acid traction battery AC motor container mast

Main information:
Load capacity: 2500kg*500mm
Lead acid battery 48V/305Ah
Chinese AC controller
AC lift motor and AC drive motor
Automatic transmission
3 stage 4.5m mast
Solid tires
Fork 1220mm
Attachments: according to customers' requirements.

ADVANTAGES
The design of Yeawey electric forklift is based on the original G series with combination of the advantages to meet the light and medium applications with great comfort and efficiency. The truck is optional to equipped with either Lead-acid battery or Li-ion battery. With lowered center of gravity and overhead guard, the truck is ideal to be used in limited spaces such as entering elevator.

Curtis controller
The trucks are equipped with Curtis controllers.CAN-bus technology makes the diagnostic and trouble shooting easier.The use of proved and certified components helps to ensure the conformity to international safety standards with all the supporting documents available as required by law.

AC maintenance-free drive motor
Adopt maintenance-free and powerful AC drive motor. Compared with traditional DC motors, our AC motors do not need to replace Carbon brushes. Equipped with speed sensor and temperature sensor, greatly improving the AC motor’s reliability.

High performance transmission:
Transmission system uses a horizontal fan-shaped drive axle arranged in parallel with a large transmission ratio. The battery is installed at the bottom of the frame.Traveling motor adopts AC maintenance-free motor.

Control valve and brake button:

Front multi-way valve operating device makes operations more comfortable.

Electromagnetic brake button cut off power at one time,making brake safer and easier.

Quite low vibration design

The hydraulic system uses a low-noise gear pump and full hydraulic power steering. Quiet and comfortable operation. Shock absorbing steer axle to protect the vehicle system and prolong the service life of the forklift.

Warranty:
The warranty period is 24 months from on board date or 2000 working hours whichever comes first.
During warranty, we offer air delivery of the spare parts within 2 working days.Besides that, we have experienced engineers to check the problems and maintenance.
Delivery time:
As a factory, we can offer fast products delivery, standard forklift is 7 working days, Forklift with options is 10-20 working days.
Should you have any questions pls feel free to let us know.

Item	Model		CPD25
1	Power type		Battery
2	Rated load	KG	2500
3	Load center distance	mm	500
4	Driving type		Seat
5	Length With fork	mm	3550
6	Length Without fork		2480
7	Whole Width		1180
8	Height no lifting frame		1995
9	Top frame height		2210
10	Max Height working		4100
11	Distance from seat to top light		1070
12	Wheel base		1650
13	Front overhang		410
14	Back overhang		420
15	Front wheel tread		1000
16	Back wheel tread		945
17	Min Floor clearance		110
18	Max lifting height		4500
19	Free lifting height		1500
20	Fork changing		1040/200
21	Min Turning radius(outside)		2285
22	Min Right angle aisle width		3995
23	Frame angle (front/back)	(°)	6/10
24	Max lifting speed without goods	mm/s	280
25	Max lifting speed with full goods	mm/s	260
26	Max speed without goods	Km/h	14
27	Max speed with full goods	Km/h	13
28	Max climbing angle	％	15
29	Self weight	Kg	3750
30	Driving Wheel		2/2
31	Tyre model		pneumatic tyre
32	Front Tyre		6.50-10
33	Rear Tyre		18×7-8
34	Hand Brake		Hydraulic Pedal
35	Brake type		M-Hand
36	Lead aicd Battery Volt/ capacity	V/Ah	48V/300
37	Lithium Battery Volt/ capacity	V/Ah	48V/206
38	Driving motor power	Kw	7.5
39	Pump power	Kw	10
