2EDGRKM-5.0 5.0mm Pitch Pcb Connector Plug In Terminal Blocks Male Female
2EDGRKM-5.0 5.0mm Pitch Pcb Connector Plug In Terminal Blocks Male Female
Product Specifications
| Pitch | 5.0mm |
| Poles | 2P-24P |
| Number of Contacts | 2-24 |
| Rated voltage | 300V |
| Reated current | 10A |
| Pin Dimensions) [mm | 3.7 |
| Temperature range | -40°C~+105°C |
| (Impulse wiithstand voltagea) [KV] |
2.5 |
| Supply Ability | 100000 Piece/ per Week |
| Stripping Length) [mm] | 15-16 |
| Contactive Coating | Tin Plated |
| Withstanding VoltagWithstanding Voltag | 2200V/1Min |
| PCB Hole Diameter) [mm] | 1.4 |
Product Application
-
industrial controls
-
lamp lighting
-
instrumentation
-
consumer electronics telecom equipment
-
transportation
How To Connect Wire ?
The 2EDGRKM-5.0 5.0mm Pitch PCB Connector Plug-In Terminal Blocks Male Female are designed for seamless integration into printed circuit boards (PCBs), providing a robust and efficient way to connect electrical wires. Here's a detailed description of how to wire and use these terminal blocks in a complementary manner:
Wiring and Complementary Use:
-
Preparation: Begin by ensuring that your PCB is properly designed to accommodate the 5.0mm pitch of the 2EDGRKM-5.0 terminal blocks. This involves having corresponding through-holes or mounting pads at the correct spacing.
-
Mounting the Terminal Blocks:
- Place the male or female terminal block onto the PCB, aligning the pins or sockets with the designated through-holes or mounting pads.
- Secure the terminal block in place using appropriate fasteners, such as screws or rivets, as per the manufacturer's instructions.
-
Connecting Wires:
- For the male terminal block, insert the stripped ends of the electrical wires into the appropriate holes, ensuring they are fully seated and making good contact with the terminals.
- With the female terminal block, connect the mating wires or cables, aligning the pins of the male block with the sockets of the female block.
-
Locking Mechanism (if applicable):
- Some terminal blocks may feature a locking mechanism to secure the wire connections. If present, engage this mechanism to ensure a secure and reliable connection.
-
Verification:
- Once all connections are made, carefully inspect each one to ensure no wires are crossed or improperly seated.
- Perform a continuity test using a multimeter to verify that all connections are electrically sound.
-
System Integration:
- Once verified, proceed with integrating the PCB and its connected terminal blocks into your larger electrical system.
Complementary Use:
- The 2EDGRKM-5.0 terminal blocks are designed to work seamlessly with each other, with the male block mating perfectly with the female block. This allows for easy assembly and disassembly, facilitating maintenance and upgrades.
- The 5.0mm pitch ensures a compact and space-efficient design, making it ideal for use in dense PCB layouts.
- By utilizing both male and female terminal blocks, you can create modular connections that can be easily rearranged or replaced as needed, enhancing the flexibility and scalability of your electrical system.
- The robust construction of these terminal blocks ensures reliable performance, even in harsh environments or under heavy loads, making them a dependable choice for a wide range of applications.
In summary, the 2EDGRKM-5.0 5.0mm Pitch PCB Connector Plug-In Terminal Blocks Male Female offer a straightforward and efficient way to connect electrical wires to PCBs. By carefully following the wiring instructions and leveraging the complementary nature of the male and female blocks, you can create reliable and flexible electrical connections that meet your system's needs.
