Used Dumper Truck Sino Truck HOWO 371 Diesel Tipper Dump Truck with Diesel Fuel Type
The blooming flowers on the construction site light up the entire projet ,colorful ,you can coose any color which u like ,including Gradient color ,army green .rainbow of seven colors etc.
| Company’s Name:ShangHai Long shou machinery company Limited |
| Address: No 3539A Jingdong Road, MinHang district.ShangHai, P. R. China |
| Contact :Olivia.He |
| Whats app/ Mobile phone:+8618701954897 |
| We chat number:18701954897 |
| E:longshoucompany163.com |
| Vehicle announcement: ZZ3317N4267C1 |
| Brand: China National Heavy Duty Truck Corporation |
| Car series: HOWO |
| Purpose: Dump truck |
| Vehicle type: whole vehicle |
| Drive mode: 8 × 4 |
| Maximum speed: 75km/h |
| Flipping form: rear unloading type |
| Tonnage level: heavy-duty trucks |
| Vehicle reference price: 34-368800 yuan |
| Chassis reference price: 285800 to 288800 yuan |
| Manufacturer: China National Heavy Duty Truck Corporation |
| • Vehicle origin: Jinan, Shandong Province |
| Vehicle parameters |
| Rated mass: 15700kg |
| Curb weight: 15170kg |
| Total weight: 31000kg |
| Vehicle length: 10825mm |
| Vehicle width: 2496mm |
| Vehicle height: 3450mm |
| Container length: 7800mm |
| Box width: 2300mm |
| Container height: 1000mm |
| Front wheelbase: 2022/2022mm |
| Rear wheelbase: 1830/1830mm |
| Front overhang: 1500mm |
| Rear overhang: 1975mm |
| Approach angle: 19 ° |
| • Separation angle: 22 ° |
| Wheelbase: 1800+4200+1350mm |
| Driver's cab |
| • Type of cab: HW76 extended type |
| • Number of passengers allowed: 2 people |
| engine |
| Engine model: China National Heavy Duty Truck WD615.96E |
| Engine form: inline six cylinder, water-cooled, four stroke, turbocharged intercooled, electronically controlled fuel injection rate fuel injection pump, EGR |
| Maximum power: 276KW |
| Maximum power speed: 2200rpm |
| Maximum torque: 1500N. m |
| Maximum torque speed: 1100-1600rpm |
| Maximum horsepower: 375 horsepower |
| Displacement: 9726mL |
| • Fuel type: diesel |
| Emission standards: National III |
| Transmission |
| Transmission model: HW19710 |
| Shift method: manual |
| • Number of forward gears: 10 gears |
| Reverse gear: 2nd gear |
| chassis |
| Chassis model: ZZ3317N4267C1 |
| Number of plate springs: 11/11/12 |
| • Clutch: Φ four hundred and thirty |
| Front axle description: HF9 disc |
| Rear axle description: AC16 |
| tyre |
| Number of tires: 12 |
| Tire specifications: 12 (11) |
|
|
|
|
|
|
