UL3512 Tinned Copper High Temperature Silicone Wire with Multiple AWG Sizes for Industrial Applications
Price:
Quotation by specification
MOQ:
1000m
Delivery Time:
7-15day
Brand:
linkecable
Product Description
Product Specifications
- Customized: Yes
- Type: Isolated
- Conductor Type: Extra Soft High Temperature Silicone Wire
- Brand Name: Linke Cable
- Conductor Material: Tinned Copper
- Insulating Material: Silicone
- Source: CN
- Qualification: UL, CCC
- Temperature Resistance: -60℃ to 200℃
- Available Specifications: 28, 26, 24, 22, 20, 18, 16, 14, 12, 10, 8, 6 AWG
- Materials: Silicone, Tinned Copper
- Scope of Application: Lithium Battery, Model Aircraft, DIY Projects
Model Aircraft Silicone Wire Specifications
| Specification | Conductor Structure | Copper Wire Diameter (mm) | Outer Diameter (mm) |
|---|---|---|---|
| 30 AWG | 11/0.08AS | 0.3 | 1.15 |
| 28 AWG | 16/0.08AS | 0.36 | 1.2 |
| 26 AWG | 30/0.08AS | 0.5 | 1.5 |
| 24 AWG | 40/0.08AS | 0.58 | 1.6 |
| 22 AWG | 60/0.08AS | 0.71 | 1.7 |
| 20 AWG | 100/0.08AS | 0.92 | 1.8 |
| 18 AWG | 150/0.08AS | 1.13 | 2.3 |
| 17 AWG | 210/0.08AS | 1.33 | 2.7 |
| 16 AWG | 252/0.08AS | 1.46 | 3 |
| 15 AWG | 300/0.08AS | 1.6 | 3.2 |
| 14 AWG | 400/0.08AS | 1.84 | 3.5 |
| 13 AWG | 500/0.08AS | 2.06 | 4 |
| 12 AWG | 680/0.08AS | 2.4 | 4.5 |
| 11 AWG | 750/0.08AS | 2.53 | 5 |
| 10 AWG | 1050/0.08AS | 2.994 | 5.5 |
| 9 AWG | 1200/0.08AS | 3.2 | 6 |
| 8 AWG | 1650/0.08AS | 3.75 | 6.3 |
| 7 AWG | 2400/0.08AS | 4.52 | 7.2 |
| 6 AWG | 3200/0.08AS | 5.22 | 8.5 |
| 5 AWG | 3998/0.08AS | 5.84 | 9.5 |
| 4 AWG | 500/0.08AS | 6.53 | 11 |
General Wire Properties
Conductor: Multiple strands of tinned copper (bare copper optional) wire stranded, according to the sixth stranded conductor GB/T3956
Insulation: High and low temperature resistant silicone rubber
Insulation Color: Brown, blue, black, gray, purple, white, orange, red, yellow, green, pink, yellow-green, etc.
Application Standards: Q/IRMV2-2008, UL758
Rated Voltage: 300/500V
Test Voltage: Insulation thickness ≤0.5mm: 2000V; Insulation thickness ≥0.5mm: 2500V
Product Images
Frequently Asked Questions
- Are you a manufacturer or trading company? We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.
- How can I get a sample to test your quality? The samples are free for you. New clients are expected to pay for the courier cost.
- What's your Minimum Order Quantity? Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.
- Can I get a discount? It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.
- Does your company accept OEM production? Yes, we can print your company name, and we even customize the quality card to promote your company.
For More Information, Please feel free to contact us!
