UL10064 Automotive Primary Wire TXL Electric Cable with XLPE Insulation and Tinned Copper Conductor for 300V Applications
Price:
Negotiable
MOQ:
1000m
Delivery Time:
7-15 days
Brand:
Linke
Product Description
|
Style/size 线材规格 AWG |
Conductor 导体 |
Insulation 绝缘 |
Max.Conductor DCResistance at20℃导体电阻 Ω/KM |
包裝 (Packing) |
|||
|
Construct to n 结构规格 |
OD (REF) |
Average Thickness 平均厚度 mm |
Min. Thickness 最小厚度 mm |
OD 外径 mm |
米/卷 Mt/coils |
||
|
32 |
7/0.08±0.008 |
0.24 |
0.06 |
0.03 |
0.38±0.05 |
/ |
610 |
|
30 |
7/0.1±0.008 |
0.3 |
0.08 |
0.05 |
0.5±0.05 |
381 |
610 |
|
28 |
7/0.12±0.008 |
0.36 |
0.12 |
0.1 |
0.64±0.08 |
239 |
610 |
|
26 |
7/0.16±0.008 |
0.48 |
0.1 |
0.07 |
0.7±0.08 |
150 |
610 |
|
24 |
7/0.2±0.008 |
0.61 |
0.13 |
0.1 |
0.9±0.08 |
94.2 |
610 |
|
22 |
19/0.15±0.008 |
0.75 |
0.13 |
0.1 |
1.05±0.08 |
59.4 |
610 |
|
20 |
19/0.185±0.008 |
0.93 |
0.17 |
0.14 |
1.35±0.1 |
36.7 |
305 |
Product Specifications
- Temperature Rating: -40°C to +125°C
- Voltage Rating: 300V
- Compliance Standards: UL Subject 758, UL 1581, C22.2
- Conductor Options: Solid or Stranded, Tinned or Bare Copper
- Wire Gauge: 32-16 AWG
- Insulation: XLPE (Cross-Linked Polyethylene)
- Flame Test: Passes UL VW-18 FT1 vertical flame test
- Uniform insulation thickness for easy stripping and cutting
- Application: General purpose internal wiring of appliances
Quality Certifications
ISO9001 and ISO13485, TS16949
CNR - Appliance Wiring Material
Extruded PVC Insulated Single, rated 105ºC, 1000V, Class I, Group A, B, or AB, FT1 and/or FT2
Extruded PVC Non-integral Jacketed Cable, rated 105°C, 1000V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
Extruded TPU Non-integral Jacketed Cable, rated 80°C, 300V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
CNR - Appliance Wiring Material
Extruded PVC Insulated Single, rated 105ºC, 1000V, Class I, Group A, B, or AB, FT1 and/or FT2
Extruded PVC Non-integral Jacketed Cable, rated 105°C, 1000V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
Extruded TPU Non-integral Jacketed Cable, rated 80°C, 300V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
Frequently Asked Questions
Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.
How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.
What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.
Can I get a discount?
It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.
Does your company accept OEM production?
Yes, we can print your company name, and we even customize the quality card to promote your company.
