20ºC Conductor-Resistance(Q/km) :≤ 0.8481

Insulation resistance :10MQ*km

Spark test(KV): 6.0

Voltage-Withstand Test : AC 2KV/min

Aging test of Jacket Tensile Strength(min.) :Elongation(min.)

Unaged : 1.05Kg /mm² 100%

Aging(136ºCx168h) : 70% 65%

Bend Radius :5XOD

Flame Rating :FT1,VW-1

Cold bend test:-40ºC

Oil resistance:yes

EV charging line is a kind of on-board high voltage cable, used to connect the charging port and battery, battery internal, battery and engine and other components, as well as battery energy storage equipment and other fields, as the carrier of power transmission. Due to the harsh application environment in the car, the high-voltage cables used for electric vehicles have very high performance requirements. Application characteristics of electric vehicle cable: small wiring space, high current and high pressure, high and low temperature environment, poor heat dissipation, harsh car driving environment, salt fog and electromagnetic field, oil and chemicals, low smoke, halogen-free flame retardant and other environmental protection and safety requirements. The EV charging cable is used to connect the ev charging device and the charging infrastructure, so as to transmit power to the electric vehicles, and is equipped with a certain number of signal lines, control lines, power auxiliary lines, etc., to ensure the accurate control and safe operation of the whole charging process. Charging cables are generally used in charging stations, parking lots, hotels, communities, garages and other areas, and portable charging cables can be placed in the car.

We have a strong R&D team,6 people in the engineering department,they all have more than 10 years of technology and experience in the field of wire and cable,professional focus on wire and cable solutions to ensure that we provide the most accurate and effective solutions to our customers.The quality control department has 10 people,from inxoming materials to shipping,esch step is strictly supervised to ensure that the products reach the customer's hands are 100% good.The production staff has more than 50 people, who are experienced in prodution.

For More Information, Please do feel free to contact us!
