4 6L Engine Capacity 10 Ton Dongfeng Light Dump Truck for Engineering Transportation
Price:
$17,917.00/units 1-2 units
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
DONGFENG
Product Description
Products Description
Dongfeng Brand new 4X2 Small Dump Truck
Truck Fatures:
1) Cummins 140HP Engine
2) 10 ton high loading capacity
3) Suitable for city transportation
Details Images
Product Paramenters
Model: | DFS3060GL6 |
Engine | |
Model | B140 33 (Cummins) |
Type | Diesel, Direct Injection,Turbo charged with Intercooler |
Max. Engine Output (HP or KW/rpm) | 103 KW(140HP) |
Max. Tourque (N.m/rpm): | 502 Nm @ 1400-1600 rpm |
Cylinder Displacement L/cc | 3900 ml |
Emission: | Euro 3 |
Gear Box | MT / Forward 5 & Reverse 1 |
Model | DF5S650 |
Suspension | Strengthen spring |
Type | Spring Leaf Tablet: 9/11+8 |
Brakes | Front&Rear drum,dual-circult service brakding system |
Clutch | |
Type: | Single,dry,diaphragm spring clutch⊙350 |
Overall Dimensions (LxWxH) mm: | 6900×2490×2800 |
Wheel Track (front/rear) mm: | 1845 / 1730 |
Overhang (Front/Rear) mm: | 1180 / 1920 |
Driving Type: | 4×2 |
Wheel Base (mm): | 3800 |
Min ground clearence (mm): | 286 |
Vehicle Weight | |
Curb weight (kg): | 4600 |
Pay Load Capacity (kg): | 10000 |
Gross vehicle weight (kg): | 14600 |
Tipper Body | |
Volume | 4500×2300×800 8.28 CUM |
Tipping Angle | 45~56° |
Cabin: | 1+2 seats / 2 doors + 1 bed, with Air conditioner |
Steering | |
Type: | Power steering |
Wheels & Tyres | |
Front: | Tire Number: 2, Tire Size: 8.25R20 |
Rear: | Tire Number: 4, Tire Size: 8.25R20 |
Performance | |
Max speed (km/h): | 85 |
