Max Torque 340Nm/rpm 22 Seater Coaster Bus 7.7m Diesel Front Engine Left Hand Drive Bus
Price:
$9,800.00/units 1-4 units
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
Dongfeng
Product Description
Product Description
Specification
Dimensions | Photo | |||||
Overall Length | 7005 mm | |||||
Overall Width | 2050 mm | |||||
Overall Height | 2640 ,2760 mm | |||||
Interior Height | 1820 mm | |||||
Wheelbase | 3935 mm | |||||
Front Overhang | 1150 mm | |||||
Rear Overhang | 1920 mm | |||||
First Step Height | 400 mm | |||||
Gross Vehicle Weight | 5900 kg | |||||
Seats Capacity | 10-26 | |||||
Rear Luggage Compartment Volume* | 0.25 m3 | |||||
Engine | ||||||
Engine Model | YC4FA130-30 | |||||
Engine Type | in-line,water-cooled, 4 cylinders, | |||||
turbocharged, electronic control, direct injection | Safety & Performance | |||||
Position/Fuel | Front/diesel | Standard | ||||
Max Output | 95 kw | ABS (Antilock Braking System) | ||||
Max Torque | 340Nm/rpm | GPS System, vehicle travelling data recorder | ||||
Displacement | 2982mL | Speed-limiting device (100km/h top ) | ||||
Emission Standard | national standard III | Safety belt equipped with every seat | ||||
Chassis | Heating system | water heating (3 radiator) | ||||
Chassis Model | EQ6680KS3T | Dongfeng Pannico top-mounted A/C 12KW(10500cal/h) | ||||
Gear box | DF5S410 | Antiskid floor, digital clock | ||||
Clutch | Single plate, dry friction, diaphragm spring /Φ325mm | Interior rearview mirror, sun visor for the driver | ||||
Front Axle | Jiang Lin (2.25T) Disc brake | Side window curtain, rear window curtain, tyres decorate cover | ||||
Rear Axles | Jiang Lin (4T), i=4.875 | 4 safety hammer, 2kg Fire Extinguisher | ||||
Suspension | Leaf spring front 3 rear 4 | Optional | ||||
Steering | Power steering | Nan Feng fuel heater YJ-Q11.6R | ||||
Brakes | Dual circuit liquid brake | LG antiskid floor, 4kg Fire Extinguisher | ||||
Fuel Tank | 300L | 7-inch color screen reversing rearview monitoring system | ||||
Tyres | 7.00R16 | Entertainment Systems & Digital Amenities | ||||
Parking Brake | central drum regulation brake | Standard | ||||
Battery/Generator | 6-QA-180, 12V/150A | MP3 radio system | ||||
Others | Adjustment arm; ABS; air dryer; copper water tank; | Digital clock | ||||
engine intake air preheater | Adjustable armrest, 2+1 layout | |||||
Body | Driver door, middle electric folding door | |||||
Body Type | Stainless steel frame, | New front and rear combination lamp | ||||
punch forming of front mold and rear mold | Front/rear fog lamp, side steering lamp, high mount stop lamp | |||||
Interior Trimming | Coaster luxurious interior trimming; | Optional | ||||
MP4/MP5 video system | ||||||
Side Window | Fully sealed, integrated splice windows in green color; | 15-inch color LCD | ||||
windscreen | Front : laminated glass; Rear : toughened glass | U flash disc, SD card | ||||
Defroster | Defroster with changeable power 24V,130W | Folding side window curtains,rolling sunshade curtains | ||||
Windscreen Wiper | Front: double arms type; Rear: single arm type | Monitoring system | ||||
