BAC Cooling Tower Parts / Black Cooling Tower Fill
BAC Cooling Tower Parts / Black Tower Fill
BAC cooling tower fillers have the following features:
- High-efficiency cooling: Covering a large vertical surface area with a thin film promotes maximum contact between water and air, thereby improving cooling efficiency
- Material: Using flame-retardant PVC material, through vacuum forming, the thermal performance of the filler is improved by an average of 7.3%
- Scope of application: Applicable to various models of cooling towers, such as TXV, FXT, S3000, FXV, HXI, CXV and HXC series
Specifications:
| Tech Date | |
| Sheet Width(mm) | 305/610mm |
| Sheet Length | 1220/1830/2440mm/customized |
| Thickness | 0.32-0.6mm/customized |
| Sheet Spacing | 20mm |
| Color | grey/white/black |
| Material | PP/PVC/CPVC |
Cooling Tower Fill Operating of Principle
- Cooling towers reject heat from water-cooled systems to the atmosphere. Hot water from the system enters the cooling tower and is distributed over the fill (heat transfer surface). Air is induced or forced through the fill, causing a small portion of the water to evaporate. This evaporation removes heat from the remaining water, which is collected in the cold water basin and returned to the system to absorb more heat. Each cooling tower line, although operating under the same basic principle of operation, is arranged a little differently.
- There are two main configurations of factory assembled cooling towers: crossflow and counterflow. In crossflow cooling towers, the water flows vertically down the fill as air flows horizontally across. In counterflow cooling towers, the water flows vertically down the fill as air flows vertically up.
Related Cooling Tower Film Fill
Supply in industry
How do fills work in the cooling tower?
Cooling towers reject heat from water-cooled system to the atmosphere. Hot water from the system enters the cooling tower and is distributed over the fill (heat transfer surface). Air is induced or forced through the fill, causing a small portion of the water to evaporate. This evaporation removes heat from the remaining water, which iscollected in the cold water basin and returned to the system to absorb more heat. Each cooling tower line, although operating under the same basic principle of operation, is arranged a little differently.
PACKING AND DELIVERY
FAQ
Q: Are you trading company or manufacturer ?
A: We are manufacturer with our own factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. Or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge. And the freight cost will on the buyer's side.
Q: What is your terms of payment ?
A: Payment<=USD1000, 100% in advance. Payment>=USD1000, 30% T/T in advance ,balance before shipment.
