13500X3000X1550 mm Flatbed Semi-Trailer for Road Construction Facility Transportation
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Peak Season Lead Time: one month, Off Season Lead Time: one month
Product Description
| Overall Dimensions | Front :14000x2600 Rear :12780x260 |
| Girder | Front Car: Upper Buy Plate 18mm, Lower Xing Plate 20mm Vertical Plate 12mm Height 580mm Rear Car: Upper Wing Plate 18mm, Lower Wing Plate 20mm Vertical Plate 12mm Height 580mm Wing Plate Quality :Q365: Web Material 700l |
| Axle | Factory Bridge, Normal Wheel Base 1850, 16ton No Abs And Brake Adjusting Arm /3/ Set |
| Tire | Factory With 12.00r20 Grain Smooth Flower 24Pcs |
| Rim | 8x18(Steel)/24/ Pcs |
| Plate Spring | 10 Pieces 16mm*120m/12/ Frame |
| Suspension | Factory With Reinforced Type |
| Bottom Plate | 3mm Thick Pattern Steel Plate |
| Front Stop | Flat Type Ladder And Frame |
| Side Beam | 180mm High Channel Steel Q355 |
| Beam | 120mm Through Beam |
| Type/Quantity Of Lock Heads | Front And Rear Vehicles Can Transport 1 40-Foot Non-Standard Container Respectively, And Can Also Transport 2 20-Foot Standard |
| Containers Respectively | |
| Poise Paint | Frame Sandblasted, Urethane Primer, Urethane Topcoat, Or powder, |
| Color To Be Determined | |
| Legs | 28 Tons Single Action/1/Set |
| Traction Pin | Front Car 90# Welding Type/16mm/1/Unit, Rear Car 90# Welding Type/12mm/1/Unit |
| Brake Air Chambers | 12 Double Chambers/Unit |
| Brake Valve | Domestic 6 Holes/1/Set |
| Spare Tire Rack | Wire Rope Type chain type |
| Toolboxes | With Side 1.6m Toolbox//Bench: (One On Each Front And Back) |
| Rope Tensioner | Standard |
| Circuit gas circuit | 24 Volt Electrical Ik, 7-Pin Jack, Sealed Wiring Harness,Standard with iron Horse brand |
| Fenders | Front Rubber. Iron Rear |
| Rear Protective Net | Weekly Style |
| Saddle | Reinforced 90# Saddle/1 |
Liangshan Hongxiang Vehicle Manufacturing Co., Ltd. is located at the foot of the famous waterside Liangshan Mountain, close to the 220 National Road and Beijing-Kowloon Railway, the scenery is pleasant and the traffic is very convenient.
The company has a large number of professional production, technical personnel. Advanced production equipment, sophisticated technology, complete testing equipment. Our company is a set of production, scientific research, sales in one of the professional enterprises. The products reach or exceed the performance indicators of other similar products in China. Products mainly include: Various series of container transport vehicles, semi-trailer, van, full trailer, Shanghai 50, Tianjin 60, Dongfang Red 1000 full trailer, and undertake special vehicle modification, design business.
We insist on high-quality products to win the market, adhere to the sincere service to return customers, our pursuit is first-class equipment, first-class management, first-class technology, first-class products. We always adhere to the quality, low price, contract, keep faith, product implementation of "three guarantees", timely delivery, thoughtful service business purposes. Every step of development, the first thought is the user, we rely on the quality of survival, to the letter of development!
Usually Our Truck can be shipped by Ro-ro ship or Bulk ship or Container or Flat rack. We has established good strategic partnership with many shipping companies which have professional logistics operation, ect to meet different requirements of different customers.We also supervise the whole process from the factory to the port designated by the customer to ensure that the ustomer's products arrive at the destination accurately and safely.
