Prefabricated Light Weight Steel Structure Chicken House Shed ISO9001 CE Certification
Prefabricated Light Weight Steel Structure Chicken House Shed Steel Poultry House
Automatic Feeding System
Feed pan is the core of feeding system. Feed in the hopper is delivered by the motor, through delivery pipe to fulfill feed pans one by one. When all feed pan is full of feed, control box will stop the motor from working; when feed in the feed pan is eaten up, control box will start the motor working again.
|
Details of broiler feeding pan |
|
|
|
number of grilles per pan |
14 |
16 |
|
Number of birds per pan can feed |
40-45 |
45-50 |
|
Distance per grill |
70mm |
70mm |
|
Density of broiler |
10-12birds/m2 |
10-12birds/m2 |
|
Max feed per pan for one bird per day |
180g/bird |
180g/bird |
|
Dimension |
330x330mm |
360x360mm |
Automatic Drinking System
This system can provide fresh and clean water for poultry which is crucial for the growth of poultry. The drinkers can be triggered from 360 degree which helps young birds start well and makes drinking easily.Automatic drinking system will include nipple drinkers, filter, pipe connection,lifting piece, dosing device, tube fix clip.s-hook,lifter, small pulley, nylon cord.
Environment Control
Environment control system has chicken grow temperature curve, minimum air volume curve, light curve, automatic control crosswise and length ways ventilate. Control exhaust fan, heater stove, curtain, cooling pad, light system and feeding line. The system can through the mobile phone to realize remote real-time monitoring and management.
Heating System
Intelligent control, high efciency and energy saving, warming fast, safe and durable, stable equipment heating effect for livestock and poultry house.
Steel Structure Shed Apecification
| Material |
Steel |
| Type | Steel Structure Poultry House, Cage Feeding |
| Warranty | Lifetime |
| Products | Piggery Shed with Automatic Equipment |
| Dimension | According to Customers’ Needs |
| Roof Live Load | 120kg/㎡ |
| Wind Resistance | Up to 275km/h Withstand Typhoons |
| Service Life | 50 Years |
| Design | 3D Chicken Cage Layout |
| Certification | ISO9001, CE, GB |
| Drawing | CAD, 3D, Sketch up, Tekla |
| After-sale Service | Online technical support, on-site installation |
Silo Attributes
|
Core Components |
Cone Plate |
Galvanized coating |
275g/㎡ |
|
Warranty |
1 Year |
Design |
Accept |
|
Weight |
628 KG |
Application |
Poultry Farm Used Feed Storage |
|
Place of Origin |
Shandong, China |
Single package size |
260X110X150 cm |
|
Brand Name |
KXD |
Life |
25-40 Years |
|
Material |
Galvanized Corrugated Sheets |
Function |
Grain Wheat Corn Storage Silos |
|
Machinery Test Report |
Provided |
Video Outgoing-inspection |
Provided |
Feeding System Composition
• Vice driver • The feed pan • Feed tube • Augor • Side feed box • The lifting device • Porching prevention device
Package & Loading
The Steel Structure Poultry House will be shipped by sea.
Delivery time will vary based on the destination and shipping method.
Customers will be provided with tracking information once the product has shipped.
Our Team
Our commitment to customer satisfaction means that we are always available to answer any questions or concerns that may arise, and we work tirelessly to ensure that our customers are fully satisfied with their purchase. We are dedicated to providing top-notch technical support and services for the Steel Structure Poultry House product.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
