Full Automatic H Type Broiler Cage System with Hot-Dip Galvanized Steel for High-Density Poultry Farming

Price Negotiable

Price: 20-80 USD per sqm

MOQ: 500 square meters

Delivery Time: 15-35days

Brand: KXD

Product Description

Full Automatic H Type Broiler Cage System Feeding Drinking Manure Cleaning

An Automatic Broiler Cage System is a fully integrated, high-density housing solution designed for commercial broiler farming. It automates the entire grow-out cycle (1-42 days), including feeding, drinking, manure removal, climate control, lighting, and even bird harvesting. Built with hot‑dip galvanized steel, it supports 3-4 tiers (H‑type) or 2 tiers (A‑type), maximizing space efficiency while improving bird health, feed conversion, and farm profitability.

Core Structure & Types

Main Types

H‑type (Vertical Stacked): 3-4 tiers, high density, full automation, ideal for large farms (30,000-100,000 birds)
A‑type (Triangle Frame): 2 tiers, lower cost, semi‑auto option, suitable for small‑to‑mid farms

Key Materials

Frame & Wire Mesh: Q235 steel, hot‑dip galvanized (zinc‑aluminum alloy), 15-20 years service life, anti‑corrosion, rust‑proof
Floor: PP plastic slats (flexible, non‑slip, reduces footpad lesions/breast blisters) or galvanized wire mesh
Manure Belt: 1.2mm PP or PVC, durable, easy to clean

Full Automation Components (All‑in‑One System)

Automatic Feeding System

Trolley Feeder: Hot‑galvanized hopper, 0.75kW motor, 8-10m/min, uniform distribution, reduces feed waste by 3-5%
Feed Trough: Hot‑galvanized steel, corrosion‑resistant, long service life

Automatic Drinking System

Nipple Drinkers: Stainless steel, pressure‑regulated, clean water, no spillage, keeps litter dry
Water Line: HDPE pipe, with filters and pressure gauges

Automatic Manure Removal System

Bottom Manure Belt: Continuous running, collects droppings, transports to house end, reduces ammonia and disease risk
Scraper: Cleans belt surface, ensures hygiene

Climate Control & Ventilation

Exhaust Fans: Hot‑galvanized frame, 430SS blades, high air volume, removes heat/ammonia
Cooling Pads: Evaporative cooling, lowers temp by 5-8°C in hot climates
Heaters: Gas/oil heaters for brooding (32-35°C for day‑old chicks)
Environment Controller: Monitors temp, humidity, ammonia; auto‑adjusts fans, pads, heaters

Automatic Lighting System

LED Lights: Dimmable, 16-23 hours light/day, promotes growth, saves energy
Timer: Auto on/off, simulates natural daylight

Automatic Harvesting System (Optional)

Pull‑out Slat Type: Cage floor slides out, birds fall onto manure belt, transported to collection table
Chain Type: Chain conveyor moves birds to house end, lifting system transfers outside
Speed: 6,000 birds/hour, reduces labor and bird injury

Core Advantages

High Space Utilization: 3-5× higher density than floor raising; 10,000-20,000 birds per house (100m×12m)
Superior Health & Hygiene: Manure‑bird separation, dry environment, lower ammonia, reduced coccidiosis/respiratory diseases; mortality rate <3%
Better Growth Performance: Uniform feed/water access, consistent climate; 42‑day weight ≥2.2kg, FCR ≤1.8
Labor Savings: 70-80% less labor; 1 worker manages 50,000 birds vs. 5,000 in floor systems
Cost Efficiency: Lower feed/medicine/labor costs; 30% energy savings vs. traditional systems
Welfare‑Friendly Design: Spacious cages, plastic slats, easy access to food/water; meets global welfare standards

Key Benefits

Faster Turnaround: Easy cleaning/disinfection, 6-7 batches/year vs. 4-5 in floor systems
Consistent Quality: Uniform growth, less weight variation, higher‑grade meat
Lower Environmental Impact: Less litter waste, manure can be processed into fertilizer
Scalable & Customizable: Modular design, expandable from 10,000 to 100,000 birds; adaptable to climate/space

Applications

Commercial Broiler Farms: 10,000-1,000,000 birds, full‑cycle production
Integrated Poultry Complexes: Hatchery → Brooder → Grow‑out → Processing
Climate‑Challenged Regions: Hot (Africa/Middle East) or cold areas (insulated houses + climate control)
Export‑Oriented Farms: Meets EU/US welfare and hygiene standards

Technical Specifications (Standard H‑type)

Cage Size	1050mm (W) × 800mm (D) × 420mm (H) per compartment
Tiers	3-4 tiers; Rows: 3-5 rows per house
Capacity	8-12 birds per compartment (100-120 cm²/bird)
Voltage	380V/50Hz or 220V/60Hz (customizable)
Certifications	ISO 9001, CE, SONCAP

Technical specifications and certifications

Why It's Ideal for Africa

Climate Adaptation: High‑volume fans + cooling pads for hot/humid conditions; corrosion‑resistant galvanized steel for coastal areas
Labor Shortage Solution: Full automation reduces reliance on scarce skilled labor
Cost‑Effective: Lower operational costs, faster ROI (2-3 years)
High Production: Maximizes output per m², critical for land‑constrained regions
