122L Lab Shaker Incubator Orbital Linear Refrigerated Shaking Incubator ST-210R
Refrigerated Orbital-Linear Shaking Incubator / Incubator Shaker ST-210R
Main Features
- Durable Exterior: Powder-coated steel construction
- Advanced Interface: 7" color touch screen LCD
- Easy Maintenance: SUS304 chamber with rounded corners for effortless cleaning
- Dual Lighting System: Illumination and UV sterilization capabilities
- Clear Visibility: Large tempered glass observation window
- High-Capacity Platform: SUS304 brushed shaking platform supports 50ml-3000ml flasks
- Space-Efficient Design: Stackable configuration (maximum 3 units)
- Versatile Motion Modes: Switchable orbital and linear shaking
- Temperature Options: Non-refrigerated (ST-210) or refrigerated (ST-210R) models
- Precise Control: P.I.D. environmental scanning controller with alarms
- Smooth Operation: Single-shaft 5-dimensions shaking mechanism
- Wide Speed Range: Adjustable from 30-300 rpm
- Eco-Friendly Refrigeration: R134a CFC-free system (ST-210R model)
- Electrical Protection: Independent leakage and overload safeguards
- Comprehensive Safety: Multiple temperature, speed, and motor protection systems
- Smart Programming: Repeat, step, and 8-segment curve settings
- Convenient Functions: Power failure recovery and parameter memory
- Sample Protection: Soft start circuit prevents liquid splash
- Reliable Motor: Maintenance-free AC brushless motor with constant torque
- Standard Connectivity: USB and RS485 data interfaces included
- Optional Upgrades: Humidity control, thermal printer, and specialized racks available
Application Benefits:
- Ideal for cell culture, microbiology, and biochemical research
- Dual shaking modes accommodate diverse experimental requirements
- Stackable design optimizes laboratory space utilization
- Enhanced safety features protect both samples and operators
- Flexible configuration options adapt to specific research needs
- Easy cleaning design reduces cross-contamination risks
Technical Data
| Control | P.I.D.(Environmental Scanning Microprocessor) |
| Display | 7" colour LCD (with touch screen) |
| Convection Mode | Forced Convection |
| Shaking Mode | Orbital-Linear switchable |
| Drive | Single-shaft balance device |
| Max. Stacking Units | 3 |
| Working Temperature | 5℃-35℃ |
| Temp. Control Range | 4℃-60℃ |
| Temp. Resolution | 0.1℃ |
| Temp. Fluctuation | ≤±0.2℃ |
| Temp. Uniformity | ≤±1℃ (at 37℃) |
| Speed Range | 30-300rpm |
| Speed Accuracy | ±1rpm |
| Orbit | Φ25 |
| Refrigerant | R134a |
| Timing Range | 0-999.59 hr/Continuous |
| Flask Platform Size | 542x445 mm |
| Flask Platform Qty. | 1 PC |
| Max. Flask Capacity | 3000mlx5, 2000mlx6,1000mlx12,500mlx20,or,250mlx30 |
| Standard Configuration | Fluorescent lamp, UV lamp, shaking platform, flask clamps |
| Optional Accessories | Universal spring shaking platform, tube rack, microplate holder, sticky pad |
| N.W./G.W. (Single Unit) | 120Kg/140Kg |
| Chamber Dimensions | 610x505x395(WxDxH,mm) |
| Overall Dimensions | 910x710x630(WxDxH,mm) |
| Packing Size | 96x76x72(LxWxH,cm) |
| Capacity | 122L |
| Power | 800W |
| Power Supply | AC 200∽240V 50-60HZ. Optional: AC110V/60Hz |
| Chamber Material | Polished SUS304 |
| Construction | Steel plate with powder coating |
Introduction about laboratory shaker
Laboratory shakers (benchtop to robust floor) provide uniform agitation by moving platform in specific pattern. Mechanical action crucial for blending, enhancing oxygen transfer, preventing solid settling—underpins standardized protocols.
Value: standardizes mixing environment; consistent, hands-free. Orbital most common; specialized: refrigerated (low temp), incubator (heated controlled atmospheres). Interfaces: advanced digital displays with menu-driven settings for accuracy/ease.
Applied in key areas: growing bacterial cultures for molecular biology, extracting analytes in environmental testing, tissue processing in histopathology. Features: adjustable orbit diameters on some models, timer with auto-stop, robust construction for demanding environments.
