Refrigerated Orbital Laboratory Incubator Shaker DS-5042SKR(A)
- Time-saving programmed operations with repeat and step functions
- Uninterrupted research through automatic power failure recovery
- Quick parameter setup using saved speed and program memory
- Dual-purpose illumination with fluorescent and UV light sources
- Clear visibility through large tempered safety glass window
- Easy maintenance with durable stainless steel interior
- Consistent performance through precision PID temperature control
- Broad compatibility with various flask sizes and accessories
- Reduced vibration through advanced drive system design
- User-friendly interface with clear backlit display
- Flexible refrigeration options for different budget requirements
- Enhanced safety with motor overheating protection
- Smooth door operation with pneumatic support system
- Optional LED culture lighting for specialized applications
- Multi-level alarm systems ensure operational safety
| Control | P.I.D. |
| Display | 7“ Touch Screen Colour LCD x 2 |
| Convection Mode | High Speed Forced Circulation |
| Shaking Mode | Orbital |
| Drive | Single-shaft balance device |
| Working Chamber | 2 Independent Chambers with 1 independent controller each |
| Chamber Material | SUS304 |
| Door | Double Doors |
| Environment Temp. | 15℃-25℃, RH20%-90% |
| Temp. Control Range | RT-15℃ to 60℃ (Min.4℃) |
| Temp. Resolution | 0.1℃ |
| Temp. Control Accuracy | <±0.2℃ |
| Temp. Uniformity | <±1℃ (at 37℃) |
| Speed Range | 30-300rpm |
| Speed Accuracy | ±1rpm |
| Programing | Repeating, Increment and 8 segment curve setting |
| Orbit | Φ25mm |
| Refrigerant | R134a |
| Timing Range | 0-999.59 Hr/Continuous |
| Platform Size (mm) | 498x460 |
| Platform Qty. | 2x dual-deck flask platforms |
| *Max. Flask Capacity | 250mlx80PCS, 500mlx64PCS, 1000mlx36PCS, or, 2000mlx24PCS |
| Chamber Dimensions | 607x506x875(WxDxH,mm) |
| Overall Dimensions | 1350x645x1620(WxDxH,mm) |
| Packing Size(LxWxH,cm) | 140x70x172 |
| Chanber Capacity | 268Lx2 |
| Standard Accessory | 4xfluorescent lamps, 4xUV lamps, 4 Shaking platform with flask clamps |
| Net Weight (Kg) | 480 |
| Power (W) | 2240 |
| Power Supply | AC 200-240V/50-60Hz. Optional: AC110V/60Hz |
| Chamber Material | Polished SUS304 Stainless Steel |
| Construction | Steel with powder coating |
A laboratory shaker is an automated instrument for agitating samples, available as benchtop or floor models. Its function is to create homogeneous mixtures by subjecting containers to continuous motion, ensuring even distribution of solutes, gases, and cells—fundamental for successful protocols in biotech, pharma, and diagnostics.
The concept is mechanization of mixing for consistency. Orbital motion is ideal for general mixing; linear for washing; rocking for gentle agitation. Advanced incubator shakers regulate temperature, CO2, and humidity with shaking, essential for biological incubations.
Applications: culturing microorganisms, mixing PCR components, facilitating chemical reactions. Features: bright digital displays, end-of-run indicators, corrosion-resistant construction. Adaptability and reliability make them indispensable for reproducible sample processing.
