6x2400ml 18x400ml High Speed Refrigerated Centrifuge Floor Standing
- Microprocessor control
- Stainless steel chamber and power coated housing
- RPM/RCF adjustable during running and automatic value calculation
- Selectable acceleration and deceleration rates ensuring high-quality separations
- LCD display for parameter setting and LED display for working status
- Display of speed, time, temperature, acceleration/deceleration, RCF, 30-program memory and error code
- Self-diagnostic system with protection of imbalance, over temperature, over speed, over voltage and electronic lock
- Motorized lid lock and manual emergency lid release in case of unexpected power interruption.
- Pneumatic spring support for easy lid opening, with hinge on the right side
- Swing-out rotor with buckets and adapters made of high-density material
- Silence-block and shock absorbers ensuring smooth and quiet operation
- Castors for convenient moving
| Model | NovaFuge F100-12R | |
| Display | LED & LCD | |
| Max. Speed | 7000rpm | |
| Max. RCF | 11500xg | |
| Max. Capacity | 6x2400ml /18x400ml blood bag | |
| Temperature Control Range | -20℃~+40℃ | |
| Temperature Control Accuracy | ±1℃ | |
| Speed Control Accuracy | ±20rpm | |
| Timing Range | 1min-99h59m | |
| Motor | Converter motor, direct drive | |
| Acceleration rate | 1~10(Programmable) | |
| Deceleration rate | 1~10(Programmable) | |
| Noise | <58dB | |
| Daily-use program | 30 | |
| Motor power | 3.7kw | |
| Refrigerator power | 2.5kw | |
| Refrigerant | R404a | |
| *Power Supply | 220V/50-60Hz,30A | |
| N.W. | 500Kg | |
| G.W. | 587Kg | |
| Dimensions(DxWxH) | 960x860x1200mm | |
| Packing Size(LxWxH) | 1150x970x1360mm | |
| *Optional: 110V/50-60Hz | ||
The function of a centrifuge is to separate heterogeneous mixtures through applied centrifugal force. By spinning a rotor at high RPM, it creates an environment where substances of different densities separate radially. Benchtop centrifuges are the workhorses for daily laboratory tasks, while floor-standing models serve as powerhouse units for demanding, large-scale applications. Operational flexibility is granted by the use of different rotors: fixed
angle and swing-bucket. To ensure a suitable match, buyers should compile a detailed list of requirements, including target speed (RPM/RCF), maximum sample volume, temperature sensitivity, and mandatory safety certifications.
