OEM Water Weight Bags 125ton Capacity For Crane Load Testing
Advanced Water Bag Solutions for Crane Load Testing
DOOWIN has leveraged over 15 years of crane load testing experience to engineer high-performance water bags that set industry standards. These innovative solutions combine durability, safety, and operational efficiency for load testing applications.
Key Features of DOOWIN Water Bags
- Engineered for Excellence
Fabricated based on two decades of crane load testing expertise.
DNV-certified ISO 9001 manufacturing ensures consistent quality.
2. Superior Construction
Made from 1900gsm heavy-duty, UV-stabilized PVC-coated PE fabric, offering:
High strength for load-bearing requirements.
Flexibility for easy storage and handling.
Longevity with durable material design.
3. Discharge Options
Traditional hose system: Standard discharge method.
OP/CP Discharge Valve: Enables one-pull rope control for quick water release. Eliminates the need for separate hose installation.
Wireless Discharge Valve
Water Bags Drop Test by TUV/NEL
Lifting Capacity & Safety
Working Load Limit (WLL): 0.25MT to 125MT.
Proof-loaded components: Lifting sets tested to 2x WLL for reliability.
Maintenance & Repair
Damaged fabric can be fixed using our Repair Kit.
Worn lifting components are easily replaceable.
Why Choose DOOWIN Water Bags?
Proven Expertise: Backed by 15+ years of field experience.
Certified Quality: Manufactured under ISO 9001 standards.
Innovative Design: OP/CP or Wireless Valve enhances operational efficiency.
Durable & Adaptable: Built for heavy-duty use with long-term reliability.
Specification of Water Bags
|
Model |
Capacity |
Max.Diameter |
Filled Height |
Gross Weight |
|---|---|---|---|---|
|
PLB-1T |
1,000 KG |
1.3m |
2.2m |
50kg |
|
PLB-2T |
2,000 KG |
1.5m |
2.9m |
65kg |
|
PLB-3T |
3,000 KG |
1.8m |
2.8m |
100kg |
|
PLB-5T |
5,000 KG |
2.2m |
3.7m |
130kg |
|
PLB-6T |
6,000 KG |
2.3m |
3.8m |
150kg |
|
PLB-8T |
8,000 KG |
2.4m |
3.9m |
160kg |
|
PLB-10T |
10,000 KG |
2.7m |
4.8m |
180kg |
|
PLB-12.5T |
12,500 KG |
2.9m |
4.9m |
220kg |
|
PLB-15T |
15,000 KG |
3.1m |
5.5m |
240kg |
|
PLB-20T |
20,000 KG |
3.4m |
5.5m |
300kg |
|
PLB-25T |
25,000 KG |
3.7m |
5.7m |
330kg |
|
PLB-30T |
30,000 KG |
3.9m |
6.3m |
360kg |
|
PLB-35T |
35,000 KG |
4.2m |
6.5m |
420kg |
|
PLB-40T |
40,000 KG |
4.3m |
7.5m |
450kg |
|
PLB-50T |
50,000 KG |
4.8m |
7.5m |
560kg |
|
PLB-55T |
55,000 KG |
4.9m |
7.8m |
600kg |
|
PLB-75T |
75,000 KG |
5.3m |
8.8m |
820kg |
|
PLB-100T |
100,000 KG |
5.7m |
8.9m |
1050kg |
|
PLB-110T |
110,000 KG |
5.8m |
9.0m |
1100kg |
Construction of Water Bags
