304 Stainless Steel Buttweld Pipe Fittings 90 Degree Stainless Elbow DN6-DN800
| Attribute | Value |
|---|---|
| Wall Thickness | SCH10-SCH160 |
| Customized Support | OEM, ODM, OBM |
| Pressure Rating | 150LB |
| Pipe Fitting Type | Elbow |
| Connection Type | Butt Welded |
| Application | Oil, Gas, Chemical, Petrochemical, Power, etc. |
| Size | DN6-DN800 |
| Standard | EN, ASTM, AISI, DIN, JIS |
| Grade | 304, 304L, 316, 316L, 321, 310s |
| Trade Terms | CNF, FOB, CIF, CFR, CNF, EXWORK |
The 304 Stainless Steel Socket Weld Fittings 90-Degree Elbows are designed for high-performance industrial applications, offering exceptional corrosion resistance and durability. Made from premium 304 stainless steel, these elbows ensure reliable performance in high-pressure and high-temperature environments.
The socket weld design provides a secure, leak-proof connection, while the 90-degree angle facilitates smooth flow direction changes. Ideal for chemical, petrochemical, and oil & gas industries, these fittings guarantee seamless integration and long-term reliability. Precision-engineered to meet industry standards, they are a trusted solution for demanding piping systems.
| Nominal Diameter | Outside Diameter | Center to End | Center to Center | Weight (kg/pc) |
|---|---|---|---|---|
| DN15 (1/2") | 21.3mm | 16mm | 38mm | 0.04-0.10kg |
| DN20 (3/4") | 26.7mm | 19mm | 38mm | 0.06-0.13kg |
| DN25 (1") | 33.4mm | 22mm | 38mm | 0.07-0.19kg |
| DN32 (1 1/4") | 42.2mm | 25mm | 48mm | 0.11-0.34kg |
| DN40 (1 1/2") | 48.3mm | 29mm | 57mm | 0.16-0.49kg |
| DN50 (2") | 60.3mm | 35mm | 76mm | 0.27-0.90kg |
| DN65 (2 1/2") | 73mm | 44mm | 95mm | 0.55-1.79kg |
| DN80 (3") | 89mm | 51mm | 114mm | 0.82-2.76kg |
| DN100 (4") | 114mm | 64mm | 152mm | 1.32-5.35kg |
| DN150 (6") | 168.3mm | 95mm | 229mm | 3.86-15.41kg |
| DN200 (8") | 219mm | 127mm | 305mm | 7.03-31.17kg |
| DN300 (12") | 325mm | 190mm | 457mm | 22.16-95.81kg |
| DN400 (16") | 426mm | 254mm | 610mm | 40.09-206.35kg |
| DN500 (20") | 529mm | 318mm | 762mm | 71.48-391.34kg |
| DN600 (24") | 630mm | 381mm | 914mm | 119.37-661.10kg |
