304 304L 8 Inch Class 150 Stainless Steel Flat Face Blind Flange AISI
Price:
Negotation
MOQ:
100KGS
Delivery Time:
2-10 work days
Brand:
Yuhao
Product Description
AISI 304 304L 8inch Class150 Stainless Steel Flat Face Blind Flange
Product Attributes
| Attribute | Value |
|---|---|
| Material | 304, 304L, 306, 306L, 316, 316L |
| Application | Connection, Decoration, oil and gas, Automative, New Energy, Chemical |
| Standard | ASTM, AISI, GB, JIS, ASME |
| Brand name | YUHAO |
| Package | Standard Seaworthy Packagel, wooden cases... |
| Certification | ISO, API, BV, CE ... |
| Connection | Welding |
| Pressure | Class150/300/600/9001500/2500 |
| Dimensions | 1/2", 2", 3", 4", 6", 8", 10", up to 24" |
| Place of origin | Zhejiang |
Product Description
A blind flange, also known as a flange cover, blind disk, or flanged pipe plug, is a solid disk without a central hole used to seal pipe openings. Its primary function is similar to that of a pipe plug or cap, but it is designed as a detachable component, making it easier to replace or maintain. By bolting it to the end of a pipe, it effectively blocks the flow of fluids or gases, providing a secure and removable closure solution.
Product Size
| DN | Pipe OD | Connection Size | Flange Thickness(mm) | C | Flagne ID | A | B | Flange OD | Bolt Hole Circle Diameter | A | B |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 10 | 17.2 | 14 | 90 | 60 | 14 | 18 | 15 | ||||
| 15 | 21.3 | 18 | 95 | 65 | 14 | 22.5 | 19 | ||||
| 20 | 26.9 | 25 | 105 | 75 | 16 | 27.5 | 26 | ||||
| 25 | 33.7 | 32 | 115 | 85 | 16 | 34.5 | 33 | ||||
| 32 | 42.4 | 38 | 140 | 100 | 18 | 43.5 | 39 | ||||
| 40 | 48.3 | 45 | 150 | 110 | 18 | 49.5 | 46 | ||||
| 50 | 60.3 | 57 | 165 | 125 | 19 | 61.5 | 59 | ||||
| 65 | 76.1 | 76 | 185 | 145 | 20 | 77.5 | 78 | ||||
| 80 | 88.9 | 89 | 200 | 160 | 20 | 90.5 | 91 | ||||
| 100 | 114.3 | 108 | 220 | 180 | 22 | 116 | 110 | ||||
| 125 | 139.7 | 133 | 250 | 210 | 22 | 143.5 | 135 | ||||
| 150 | 168.3 | 159 | 285 | 240 | 24 | 170.5 | 161 | ||||
| 200 | 219.1 | 219 | 340 | 295 | 24 | 221.5 | 222 | ||||
| 250 | 273 | 273 | 395 | 350 | 26 | 276.5 | 276 | ||||
| 300 | 323.9 | 325 | 445 | 400 | 26 | 328 | 328 | ||||
| 350 | 355.6 | 377 | 505 | 460 | 28 | 360 | 381 | ||||
| 400 | 406.4 | 426 | 565 | 515 | 32 | 411 | 430 | ||||
| 450 | 457 | 480 | 615 | 565 | 36 | 462 | 485 | ||||
| 500 | 508 | 530 | 670 | 620 | 38 | 513.5 | 535 | ||||
| 600 | 610 | 630 | 780 | 725 | 42 | 616.5 | 636 |
Product Images
Frequently Asked Questions
Q1: Do you provide samples? Is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q2: Can you supply what's the service?
A: We can supply the kinds of metal raw materials and products, such as pipes, pipe fittings, flanges, coil, sheet, round bar and so on.
Q3: Can I customize products?
A: Yes. Let me know the specific customization requirements, and I will get back to you as soon as possible.
Q4: What is your minimum order quantity?
A: The MOQ for each product is different, so it would be recommended to refer to the detail page of the product you are interested in. If you need further clarification, send me the product link, and I will reply as soon as possible.
Q5: How long is your production lead time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
