ASTM ASME 304L Stainless Steel Flanges SS Blind Flange 1/2 Inch To 24 Inch
Price:
Negotation
MOQ:
100KGS
Delivery Time:
2-10 work days
Brand:
Zhejiang
Product Description
ASTM ASME 304L Stainless Steel Flanges Ss Blind Flange 1/2inch To 24inch
Product Attributes
| Attribute | Value |
|---|---|
| Material | 304, 316, 306, 304L, 316L, 306L |
| Application | Connection, Decoration, oil and gas, Automotive, Water Disposal, Natural Gas |
| Standard | ASME, ASTM, AISI, GB, JIS |
| Flange face type | Blind |
| Package | Standard Seaworthy Packaging, wooden cases |
| Certification | ISO, API, BV, CE |
| Connection | Welding |
| Pressure | Class150/300/600/9001500/2500 |
| Dimensions | 1/2", 2", 3", 4", 6", 8", 10", up to 24" |
| Brand Name | Zhejiang |
Product Description
A blind flange, also referred to as a flange cover, blind disk, or flanged pipe plug, is a solid disk without a center hole, primarily used to seal pipe openings. Its function resembles that of a pipe plug or cap, but it is designed as a detachable component, simplifying replacement and maintenance. When bolted to the end of a pipe, it effectively prevents the flow of fluids or gases, providing a secure yet removable sealing solution. This design combines practicality and ease of use, making it a reliable and convenient option for pipeline systems requiring accessible and dependable closures.
Product Size
| DN | Pipe OD | Connection Size | Flange Thickness(mm) | C | Flange ID |
|---|---|---|---|---|---|
| 10 | 17.2 | 14 | 90 | 60 | 14 |
| 15 | 21.3 | 18 | 95 | 65 | 14 |
| 20 | 26.9 | 25 | 105 | 75 | 16 |
| 25 | 33.7 | 32 | 115 | 85 | 16 |
| 32 | 42.4 | 38 | 140 | 100 | 18 |
| 40 | 48.3 | 45 | 150 | 110 | 18 |
| 50 | 60.3 | 57 | 165 | 125 | 19 |
| 65 | 76.1 | 76 | 185 | 145 | 20 |
| 80 | 88.9 | 89 | 200 | 160 | 20 |
| 100 | 114.3 | 108 | 220 | 180 | 22 |
| 125 | 139.7 | 133 | 250 | 210 | 22 |
| 150 | 168.3 | 159 | 285 | 240 | 24 |
| 200 | 219.1 | 219 | 340 | 295 | 24 |
| 250 | 273 | 273 | 395 | 350 | 26 |
| 300 | 323.9 | 325 | 445 | 400 | 26 |
| 350 | 355.6 | 377 | 505 | 460 | 28 |
| 400 | 406.4 | 426 | 565 | 515 | 32 |
| 450 | 457 | 480 | 615 | 565 | 36 |
| 500 | 508 | 530 | 670 | 620 | 38 |
| 600 | 610 | 630 | 780 | 725 | 42 |
Product Images
Frequently Asked Questions
Q1: How do you ensure product quality?
A: We have a dedicated team of experts who rigorously inspect each stage of the production process. Every product undergoes quality testing at our factory before it is shipped.
Q2: Can you supply what's the service?
A: We can supply the kinds of metal raw materials and products, such as pipes, pipe fittings, flanges, coil, sheet, round bar and so on.
Q3: Can I customize products?
A: Yes. Let me know the specific customization requirements, and I will get back to you as soon as possible.
Q4: What is your minimum order quantity?
A: The MOQ for each product is different, so it would be recommended to refer to the detail page of the product you are interested in. If you need further clarification, send me the product link, and I will reply as soon as possible.
Q5: Where is your factory located?
A: Our factory is located in Wenzhou City, Zhejiang Province, China.
