DN15 To DN2000 RF Stainless Steel Flanges AISI Stainless Steel Slip On Flange
Price:
Negotation
MOQ:
100KGS
Delivery Time:
2-10 work days
Brand:
Yuhao
Product Description
DN15 To DN2000 RF Stainless Steel Flanges AISI Stainless Steel Slip On Flange
Product Specifications
Material:
304, 304L, 306, 306L
Application:
Connection, Decoration, Oil and Gas, Automotive, Water Disposal, Natural Gas
Standard:
ASTM, AISI, GB, JIS
Shape:
Raising face, Flat face, Tongue face, Groove face
Package:
Standard Seaworthy Packaging, wooden cases
Certification:
ISO, API, BV, CE
Connection:
Welding
Pressure:
Class150/300/600/9001500/2500
Technique:
Forged
Model Number:
DN15~DN2000
Outer Diameters:
1/2'', 2'', 3'', 4'', 6'', 8'', 10'', 12'', to 24"
Product Description
Slip on flange, also called SO flange, is designed with an internal diameter slightly larger than the pipe to slide over the pipe end. The flange connects to equipment or pipe through fillet welds at both the top and bottom.
Product Dimensions
| DN | Pipe OD | Connection Size | Flange Thickness (mm) | Flange ID |
|---|---|---|---|---|
| 10 | 17.2 | 14 | 14 | 15 |
| 15 | 21.3 | 18 | 14 | 19 |
| 20 | 26.9 | 25 | 16 | 26 |
| 25 | 33.7 | 32 | 16 | 33 |
| 32 | 42.4 | 38 | 18 | 39 |
| 40 | 48.3 | 45 | 18 | 46 |
| 50 | 60.3 | 57 | 19 | 59 |
| 65 | 76.1 | 76 | 20 | 78 |
| 80 | 88.9 | 89 | 20 | 91 |
| 100 | 114.3 | 108 | 22 | 110 |
| 125 | 139.7 | 133 | 22 | 135 |
| 150 | 168.3 | 159 | 24 | 161 |
| 200 | 219.1 | 219 | 24 | 222 |
| 250 | 273 | 273 | 26 | 276 |
| 300 | 323.9 | 325 | 26 | 328 |
| 350 | 355.6 | 377 | 28 | 381 |
| 400 | 406.4 | 426 | 32 | 430 |
| 450 | 457 | 480 | 36 | 485 |
| 500 | 508 | 530 | 38 | 535 |
| 600 | 610 | 630 | 42 | 636 |
Product Images
Frequently Asked Questions
Q1: Do you produce non-standard items?
A: Yes, we do. Send your specification drawings to our sales representative for a quotation.
Q2: Are you manufacturer or trading company?
A: We are both manufacturer and trading company with over 12 years export experience.
Q3: Do you provide samples?
A: Yes, stored samples are free, but we don't cover express shipping costs.
Q4: How is the after-sales service?
A: We guarantee product quality. If products don't meet contract specifications, we will send replacements.
Q5: Which payment terms do you accept?
A: We accept TT, LC, DP, DA, Western Union or other negotiable payment methods.
