F316 F316L F304L Stainless Steel Screwed Pipe Fittings BSPT Stainless Steel Hex Nipple
Price:
Negotiation
MOQ:
100kgs
Delivery Time:
5-15days
Brand:
YUHAO
Product Description
F316 F316L F304L Stainless Steel Screwed Pipe Fittings BSPT Stainless Steel Hex Nipple
Product Specifications
| Attribute | Value |
|---|---|
| Shape | Hexagonal |
| Connection Type | Threaded or Socket Welded |
| Application | Oil and Gas/Petrochemical/Chemical/Automotive |
| End Type | Male/Female |
| Thread Type | NPT/BSPT/RC/R |
| Size | 1/8"-32" |
| Material | F304 F316 F316L F304L |
| Standard | DIN, ANSI, ASTM, JIS, GB |
| Packing | Wooden case, Bags, Pallets |
| Thread | BSPP BSPT NPT |
Product Description
The Stainless Steel Hexagonal Nipple in F304, F316, F316L, and F304L grades is engineered for precision and durability in chemical engineering applications. Manufactured from high-quality stainless steel, it offers exceptional corrosion resistance, making it ideal for harsh chemical environments.
Featuring BSPT (British Standard Pipe Taper) threads, it ensures secure, leak-proof connections in high-pressure and high-temperature systems. The hexagonal design allows for easy installation and maintenance. Suitable for industries such as petrochemical, pharmaceutical, and food processing, this nipple guarantees reliable performance, superior weldability, and long-term durability, meeting the highest industry standards for critical applications.
Product Dimensions
| DN | NPS | OD | Nominal Wall Thickness |
|---|---|---|---|
| 6 | 1/8 | 10.3 | 1.24 | 1.73 | 2.41 | - | - | - | 1.73 | 1.73 | - | 2.41 |
| 8 | 1/4 | 13.7 | 1.65 | 2.24 | 3.02 | - | - | - | 2.24 | 2.24 | - | 3.02 |
| 10 | 3/8 | 17.1 | 1.65 | 2.31 | 3.2 | - | - | - | 2.31 | 2.31 | - | 3.2 |
| 15 | 1/2 | 21.3 | 1.65 | 2.11 | 2.77 | 3.73 | - | - | 2.77 | 2.77 | - | 3.73 |
| 20 | 3/4 | 26.7 | 1.65 | 2.11 | 2.87 | 3.91 | - | - | 2.87 | 2.87 | - | 3.91 |
| 25 | 1 | 33.4 | 1.65 | 2.77 | 3.38 | 4.55 | - | - | 3.38 | 3.38 | - | 4.55 |
| 32 | 1 1/4 | 42.2 | 1.65 | 2.77 | 3.56 | 4.85 | - | - | 3.56 | 3.56 | - | 4.85 |
| 40 | 1 1/2 | 48.3 | 1.65 | 2.77 | 3.68 | 5.08 | - | - | 3.68 | 3.68 | - | 5.08 |
| 50 | 2 | 60.3 | 1.65 | 2.77 | 3.91 | 5.54 | - | - | 3.91 | 3.91 | - | 5.54 |
| 65 | 2 1/2 | 73 | 2.11 | 3.05 | 5.16 | 7.01 | - | - | 5.16 | 5.16 | - | 7.01 |
| 80 | 3 | 88.9 | 2.11 | 3.05 | 5.49 | 7.62 | - | - | 5.49 | 5.49 | - | 7.62 |
| 90 | 3 1/2 | 101.6 | 2.11 | 3.05 | 5.74 | 8.08 | - | - | 5.74 | 5.74 | - | 8.08 |
| 100 | 4 | 114.3 | 2.11 | 3.05 | 6.02 | 8.56 | - | - | 6.02 | 6.02 | - | 8.56 |
| 125 | 5 | 141.3 | 2.77 | 3.4 | 6.55 | 9.53 | - | - | 6.55 | 6.55 | - | 9.53 |
| 150 | 6 | 168.3 | 2.77 | 3.4 | 7.11 | 10.97 | - | - | 7.11 | 7.11 | - | 10.97 |
| 200 | 8 | 219.1 | 2.77 | 3.76 | 8.18 | 12.7 | - | 6.35 | 7.04 | 8.18 | 8.18 | 10.31 | 12.7 |
| 250 | 10 | 273 | 3.4 | 4.19 | 9.27 | 12.7 | - | 6.35 | 7.8 | 9.27 | 9.27 | 12.7 | 12.7 |
| 300 | 12 | 323.8 | 3.96 | 4.57 | 9.53 | 12.7 | - | 6.35 | 8.38 | 9.53 | 10.31 | 14.27 | 12.7 |
| 350 | 14 | 355.6 | 3.96 | 4.78 | - | - | 6.35 | 7.92 | 9.53 | 9.53 | 11.13 | 15.09 | 12.7 |
| 400 | 16 | 406.4 | 4.19 | 4.78 | - | - | 6.35 | 7.92 | 9.53 | 9.53 | 12.7 | 16.66 | 12.7 |
| 450 | 18 | 457 | 4.19 | 4.78 | - | - | 6.35 | 7.92 | 11.13 | 9.53 | 14.27 | 19.05 | 12.7 |
| 500 | 20 | 508 | 4.78 | 5.54 | - | - | 6.35 | 9.53 | 12.7 | 9.53 | 15.09 | 20.62 | 12.7 |
Product Images
Frequently Asked Questions
Q1: Do you have any Certification?
A: Yes we have TUV ISO9001-2015 and Pressure Equipment Directive 2014/68/EU(EN-10204 3.1/3.1B)
Q2: Can we visit your factory?
A: Sure, we welcome you to visit our factory, check our production lines and know more about our strength and quality.
Q3: What's your delivery time?
A: Normally in 5-7 days, we will make the delivery as soon as possible with the guarantee quality.
Q4: Can I get some samples?
A: We are glad to provide free samples to you, but we do not offer the freight.
Q5: What is the payment term?
A: T/T & L/C are the preferred payment terms. Also Western-Union is acceptable for low value payment, like samples' Express fee.
