DIN ANSI ASTM Stainless Steel Screwed Pipe Fittings F316L F304L Stainless Steel Hex Nipple
Price:
Negotiation
MOQ:
100kgs
Delivery Time:
5-15days
Brand:
YUHAO
Product Description
DIN ANSI ASTM Stainless Steel Screwed Pipe Fittings F316L F304L Stainless Steel Hex Nipple
Product Specifications
| Attribute | Value |
|---|---|
| Shape | Hexagonal |
| Connection Type | Threaded or Socket Welded |
| Application | Petrochemical, Oil and Gas, Chemical, Power Generation, Automotive, etc. |
| End Type | Male |
| Thread Type | NPT/BSPT/RC/R |
| Size | 1/8"-32" |
| Material | F304, F316, F316L, F304L |
| Standard | DIN, ANSI, ASTM, JIS, GB |
| Packing | Wooden case, Bags, Pallets |
| Thread | BSPP, BSPT, NPT |
Product Description
The Stainless Steel Hexagonal Nipple, available in F304, F316, F316L, and F304L grades, is designed for precision and durability in demanding chemical engineering applications. Crafted from high-quality stainless steel, it provides exceptional corrosion resistance, making it suitable for harsh chemical environments. Equipped with BSPT (British Standard Pipe Taper) threads, it ensures secure, leak-proof connections in high-pressure and high-temperature systems. The hexagonal design facilitates easy installation and maintenance. Ideal for industries like petrochemical, pharmaceutical, and food processing, this nipple offers reliable performance, superior weldability, and long-term durability, meeting the highest industry standards for critical applications.
Product Dimensions
| DN | NPS | OD | Nominal Wall Thickness |
|---|---|---|---|
| 6 | 1/8 | 10.3 | 1.24 | 1.73 | 2.41 |
| 8 | 1/4 | 13.7 | 1.65 | 2.24 | 3.02 |
| 10 | 3/8 | 17.1 | 1.65 | 2.31 | 3.2 |
| 15 | 1/2 | 21.3 | 1.65 | 2.11 | 2.77 | 3.73 |
| 20 | 3/4 | 26.7 | 1.65 | 2.11 | 2.87 | 3.91 |
| 25 | 1 | 33.4 | 1.65 | 2.77 | 3.38 | 4.55 |
| 32 | 1 1/4 | 42.2 | 1.65 | 2.77 | 3.56 | 4.85 |
| 40 | 1 1/2 | 48.3 | 1.65 | 2.77 | 3.68 | 5.08 |
| 50 | 2 | 60.3 | 1.65 | 2.77 | 3.91 | 5.54 |
| 65 | 2 1/2 | 73 | 2.11 | 3.05 | 5.16 | 7.01 |
| 80 | 3 | 88.9 | 2.11 | 3.05 | 5.49 | 7.62 |
| 90 | 3 1/2 | 101.6 | 2.11 | 3.05 | 5.74 | 8.08 |
| 100 | 4 | 114.3 | 2.11 | 3.05 | 6.02 | 8.56 |
| 125 | 5 | 141.3 | 2.77 | 3.4 | 6.55 | 9.53 |
| 150 | 6 | 168.3 | 2.77 | 3.4 | 7.11 | 10.97 |
| 200 | 8 | 219.1 | 2.77 | 3.76 | 8.18 | 12.7 |
| 250 | 10 | 273 | 3.4 | 4.19 | 9.27 | 12.7 |
| 300 | 12 | 323.8 | 3.96 | 4.57 | 9.53 | 12.7 |
| 350 | 14 | 355.6 | 3.96 | 4.78 | 9.53 | 12.7 |
| 400 | 16 | 406.4 | 4.19 | 4.78 | 9.53 | 12.7 |
| 450 | 18 | 457 | 4.19 | 4.78 | 9.53 | 12.7 |
| 500 | 20 | 508 | 4.78 | 5.54 | 9.53 | 12.7 |
Product Images
Frequently Asked Questions
Q1: Do you provide samples? Is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q2: Can we visit your factory?
A: Sure, we welcome you to visit our factory, check our production lines and know more about our strength and quality.
Q3: What's your delivery time?
A: Normally in 5-7 days, we will make the delivery as soon as possible with the guarantee quality.
Q4: Can I get some samples?
A: We are glad to provide free samples to you, but we do not offer the freight.
Q5: How long is your production lead time?
A: Generally it is 5-10 days if the goods are in stock. Or it is 15-20 days if the goods are not in stock, it is according to quantity.
