316L 321 310S Stainless Steel Welded Pipes Offshore Industry 316 Stainless Steel Tubing
Price:
Negotiation
MOQ:
100kgs
Delivery Time:
3-10days
Brand:
Yuhao
Product Description
316L 321 310S Stainless Steel Welded Pipes for Offshore Industry
Product Specifications
| Attribute | Value |
|---|---|
| Material | 304, 304L, 316, 316L, 321, 310S |
| OD | 3mm-3000mm |
| WT | 0.5mm-50mm |
| Length | 5800mm, 6000mm, 12000mm or as requested |
| Surface | Polished 180G/240G/320G/600G |
| Price Terms | EXW, FOB, CIF and so on |
| Package | Packed in sea-worth bundles or Plywood cases |
| Standard | ASTM, AISI, GB, JIS, ANSI |
| Applications | Aircraft and Aerospace, Automobile Industry, Heavy Industry |
| Brand Name | Yuhao |
| Corrosion Resistance | Acid Resistance, Alkali Resistance, Oxidation Resistance |
Product Description
Stainless steel welded tubes are durable and cost-effective pipes created by welding stainless steel strips or coils. These tubes are widely used in industries such as construction, automotive, and chemical processing due to their strength, corrosion resistance, and versatility. Available in various grades like 304 and 316, they are suitable for applications ranging from structural frameworks to fluid transportation. The welding process ensures consistent quality and dimensional accuracy, while the polished or brushed finish enhances their appearance for decorative uses. Lightweight yet robust, stainless steel welded tubes are easy to install and maintain, making them a reliable choice for both industrial and commercial projects.
Pipes Size - ASTM A312/A778(B36.19)
| NPS | INCH | O.D | 5S | 10S | 40S |
|---|---|---|---|---|---|
| 8 | 1/4'' | 13.72 | 1.24 | 1.65 | 2.24 |
| 10 | 3/8'' | 17.15 | 1.24 | 1.65 | 2.31 |
| 15 | 1/2'' | 21.34 | 1.65 | 2.11 | 2.77 |
| 20 | 3/4'' | 26.67 | 1.65 | 2.11 | 2.87 |
| 25 | 1'' | 33.4 | 1.65 | 2.77 | 3.38 |
| 32 | 1-1/4'' | 42.16 | 1.65 | 2.77 | 3.56 |
| 40 | 1-1/2'' | 48.26 | 1.65 | 2.77 | 3.68 |
| 50 | 2'' | 60.33 | 1.65 | 2.77 | 3.91 |
| 65 | 2-1/2'' | 73.03 | 2.11 | 3.05 | 5.16 |
| 80 | 3'' | 88.9 | 2.11 | 3.05 | 5.49 |
| 90 | 3-1/2'' | 101.6 | 2.11 | 3.05 | 5.74 |
| 100 | 4'' | 114.3 | 2.11 | 3.05 | 6.02 |
| 125 | 5'' | 141.3 | 2.77 | 3.4 | 6.55 |
| 150 | 6'' | 168.28 | 2.77 | 3.4 | 7.11 |
| 200 | 8'' | 219.08 | 2.77 | 3.76 | 8.18 |
| 250 | 10'' | 273.05 | 3.4 | 4.19 | 9.27 |
| 300 | 12'' | 323.85 | 3.96 | 4.57 | 9.53 |
Pipes Size - JIS G3459
| NPS | INCH | O.D | 5S | 10S | 20S | 40S |
|---|---|---|---|---|---|---|
| 8 | 1/4'' | 13.8 | 1.2 | 1.65 | 2.0 | 2.2 |
| 10 | 3/8'' | 17.3 | 1.2 | 1.65 | 2.0 | 2.3 |
| 15 | 1/2'' | 21.7 | 1.65 | 2.1 | 2.5 | 2.8 |
| 20 | 3/4'' | 27.2 | 1.65 | 2.1 | 2.5 | 2.9 |
| 25 | 1'' | 34 | 1.65 | 2.8 | 3.0 | 3.4 |
| 32 | 1-1/4'' | 42.7 | 1.65 | 2.8 | 3.0 | 3.6 |
| 40 | 1-1/2'' | 48.6 | 1.65 | 2.8 | 3.0 | 3.7 |
| 50 | 2'' | 60.5 | 1.65 | 2.8 | 3.5 | 3.9 |
| 65 | 2-1/2'' | 76.3 | 2.1 | 3.0 | 3.5 | 5.2 |
| 80 | 3'' | 89.1 | 2.1 | 3.0 | 4.0 | 5.5 |
| 90 | 3-1/2'' | 101.6 | 2.1 | 3.0 | 4.0 | 5.7 |
| 100 | 4'' | 114.3 | 2.1 | 3.0 | 4.0 | 6.0 |
| 125 | 5'' | 139.8 | 2.8 | 3.4 | 5.0 | 6.6 |
| 150 | 6'' | 165.2 | 2.8 | 3.4 | 5.0 | 7.1 |
| 200 | 8'' | 216.3 | 2.8 | 4.0 | 6.5 | 8.2 |
| 250 | 10'' | 267.4 | 3.4 | 4.0 | 6.5 | 9.3 |
| 300 | 12'' | 318.5 | 3.4 | 4.5 | 6.5 | 10.3 |
Product Images
Frequently Asked Questions
Q1: How do you ensure product quality?
A: We have a dedicated team of experts who rigorously inspect each stage of the production process. Every product undergoes quality testing at our factory before it is shipped.
Q2: Can you reply to messages in a timely manner?
A: Contact us with your detailed inquiry, you will be replied within 6 hours.
Q3: Can I customize products?
A: Yes. Let me know the specific customization requirements, and I will get back to you as soon as possible.
Q4: What about your delivery time if we placed order?
A: We have large of ready stock, in general we can delivery within 2-10 days.
Q5: Which payment terms you can accept?
A: We can accept TT, LC, DP, DA, Western Union or Negotiation.
