PN16 Manual Actuated 2 Inch Stainless Steel Valve 1PC Ball Valve
| Attribute | Value |
|---|---|
| Durability | High |
| Operation | Manual or Actuated |
| Material | 201 304, 304L, 306, 306L |
| Standard | ASTM, JIS, GB, AISI, DIN, BS, EN |
| Application | Flow Control |
| Applicable Media | Water, Oil, Steam, Nitric Acid, Acetic Acid, etc. |
| Corrosion Resistance | High |
| Nominal Diameter | 1/4"~4" (DN6~DN100) |
| Application Scope | Industrial, Chemical, Oil & Gas, Water Treatment, etc. |
| Thread | NPT, BSPT |
1/4"-2", 304/316L, PN16 Manual or Actuated Stainless Steel 1PC Ball Valve
The 304 Stainless Steel One-Piece Ball Valve is a robust and dependable valve designed for diverse industrial applications. Constructed from 304 stainless steel, it provides exceptional corrosion resistance and a compact, maintenance-friendly design.
- High durability construction
- Double-seated PTFE-coated ball for leak-tight sealing
- Easy operation mechanism
- Ideal for water treatment, chemical processing, pharmaceutical, food and beverage, oil and gas, and HVAC systems
- Operating temperature range: -20°C to 180°C
- Maximum pressure: 100 bar
| DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 130 | 140 | 150 | 165 | 180 | 200 | 220 | 250 | 280 | 320 | 360 | 400 |
| H | 59 | 63 | 75 | 85 | 95 | 107 | 142 | 152 | 178 | 252 | 272 | 342 |
| W | 130 | 130 | 160 | 180 | 230 | 230 | 400 | 400 | 650 | 1050 | 1050 | 1410 |
| Wt(Kg) | 2.5 | 3 | 5 | 6 | 7 | 10 | 15 | 19 | 33 | 58 | 93 | 160 |
Quality is priority. We pay much attention to the quality check. Every product will be fully assembled and carefully tested before it's packed for shipment.
We can supply the kinds of metal raw materials and products, such as pipes, pipe fittings, flanges, coil, sheet, round bar and so on.
Yes. Let me know the specific customization requirements, and I will get back to you as soon as possible.
We have large of ready stock, in general we can delivery within 2-10 days.
We can accept TT, LC, DP, DA, Western Union or Negotiation.
