PN16 1pcs Ball Stainless Steel Valve NPT BSPT Flow Control 1 Inch
Price:
Negotiation
MOQ:
100kgs
Delivery Time:
3-10days
Brand:
YUHAO
Product Description
PN16 1pcs Stainless Ball Valve NPT BSPT Flow Control 1 Inch Stainless Steel Ball Valve
Product Specifications
| Attribute | Value |
|---|---|
| Durability | High |
| Operation | Manual or Actuated |
| Material | 201 304, 304L, 306, 306L |
| Standard | ASTM, JIS, GB, AISI, DIN, BS, EN |
| Application | Flow Control |
| Applicable Media | Petroleum, Chemical, Metallurgy, Light Industry, Papermaking, Power Station, Refrigeration, etc. |
| Working Pressure | 1000 WOG |
| Nominal Diameter | 1/4"~4" (DN6~DN100) |
| Application Scope | Industrial, Chemical, Oil & Gas, Water Treatment, etc. |
| Thread | NPT, BSPT |
Product Description
1/4"-2", 304/316L, PN16 NPT, BSPT Flow Control Stainless Steel 1PC Ball Valve
The 304 Stainless Steel One-Piece Ball Valve is a durable and reliable choice for a wide range of industrial uses. Constructed from 304 stainless steel, it provides excellent corrosion resistance and a compact design for easy maintenance.
- High durability construction
- Double-seated PTFE-coated ball for leak-tight performance
- Smooth, user-friendly operation
- Ideal for water treatment, chemical processing, pharmaceuticals, food and beverage, oil and gas, and HVAC systems
- Operating temperature range: -20°C to 180°C
- Maximum pressure: 100 bar
Product Dimensions
PN1.6MPa Main connection dimensions and weight
| DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 130 | 140 | 150 | 165 | 180 | 200 | 220 | 250 | 280 | 320 | 360 | 400 |
| H | 59 | 63 | 75 | 85 | 95 | 107 | 142 | 152 | 178 | 252 | 272 | 342 |
| W | 130 | 130 | 160 | 180 | 230 | 230 | 400 | 400 | 650 | 1050 | 1050 | 1410 |
| Wt(Kg) | 2.5 | 3 | 5 | 6 | 7 | 10 | 15 | 19 | 33 | 58 | 93 | 160 |
PN2.5MPa Main connection dimensions and weight
| DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 130 | 140 | 150 | 165 | 180 | 200 | 220 | 250 | 320 | 400 | 400 | 550 |
| H | 59 | 63 | 75 | 97 | 107 | 142 | 152 | 178 | 252 | 272 | 342 | 345 |
| W | 130 | 130 | 160 | 230 | 230 | 400 | 400 | 700 | 1100 | 1100 | 1500 | 1500 |
| Wt(Kg) | 2.5 | 3 | 5 | 6 | 7.5 | 10 | 15 | 20 | 33 | 60 | 93 | 175 |
PN4.0MPa Main connection dimensions and weight
| DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 130 | 140 | 150 | 180 | 200 | 220 | 250 | 280 | 320 | 400 | 400 | 400 |
| H | 59 | 63 | 75 | 85 | 95 | 107 | 142 | 152 | 178 | 252 | 272 | 342 |
| W | 130 | 130 | 160 | 230 | 230 | 400 | 400 | 700 | 1100 | 1100 | 1500 | 1500 |
| Wt(Kg) | 3 | 4 | 5 | 7 | 9 | 12 | 18 | 28 | 46 | 75 | 106 | 190 |
Product Images
Frequently Asked Questions
Q1: How is the quality?
A: Quality is priority. We pay much attention to the quality check. Every product will be fully assembled and carefully tested before it's packed for shipment.
Q2: Can I customize products?
A: Yes. Let me know the specific customization requirements, and I will get back to you as soon as possible.
Q3: How long is your production lead time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q4: What about your delivery time if we placed order?
A: We have large of ready stock,in general we can delivery within 2-10days.
Q5: Which payment terms you can accept?
A: We can accept TT,LC,DP,DA,Western Union or Negotiation.
