ANSI 150lb JIS Stainless Steel Check Valve PN16 WCB Manual API6D Flanged 3PC SS316L
Price:
Negotiation
MOQ:
100kgs
Delivery Time:
3-10days
Brand:
YUHAO
Product Description
ANSI 150lb JIS Stainless Steel Check Valve Pn16 WCB Manual API6D Flanged 3PC Ss316l
Product Specifications
| Attribute | Value |
|---|---|
| Standard | ASTM, JIS, GB, AISI, DIN, BS, EN |
| Bonnet Style | Threaded or Welded |
| Applications | Industrial, Chemical, Oil & Gas, Water Treatment |
| Thread | NPT, BSPT |
| Port size | 1/8"-46" |
| Pressure | High/Medium/Low Pressure |
| Working pressure | 1000PSI/PN63 |
| Color | Silver, Chrome, White, Custom, Grey |
| Brand | YUHAO |
| Temperature of media | Medium, Normal, High Temperature |
Product Description
The ANSI 150LB/JIS 10K/DIN PN16 WCB Manual API6D 3-Piece Ball Valve is designed for high-performance industrial applications. Available in sizes from 1/2 inch to 80 inches, it features a robust WCB body with SS304/316 stainless steel components, ensuring excellent corrosion resistance and durability. Compliant with API6D standards, this valve is suitable for high-pressure and high-temperature environments. The flanged design allows for secure, leak-proof connections, while the manual operation ensures precise flow control. Ideal for oil & gas, petrochemical, and water treatment industries, this valve guarantees reliability, longevity, and compliance with international standards.
Product Dimensions and Weight
PN1.6MPa Main connection dimensions and weight
| DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 130 | 140 | 150 | 165 | 180 | 200 | 220 | 250 | 280 | 320 | 360 | 400 |
| H | 59 | 63 | 75 | 85 | 95 | 107 | 142 | 152 | 178 | 252 | 272 | 342 |
| W | 130 | 130 | 160 | 180 | 230 | 230 | 400 | 400 | 650 | 1050 | 1050 | 1410 |
| Wt(Kg) | 2.5 | 3 | 5 | 6 | 7 | 10 | 15 | 19 | 33 | 58 | 93 | 160 |
PN2.5MPa Main connection dimensions and weight
| DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 130 | 140 | 150 | 165 | 180 | 200 | 220 | 250 | 320 | 400 | 400 | 550 |
| H | 59 | 63 | 75 | 97 | 107 | 142 | 152 | 178 | 252 | 272 | 342 | 345 |
| W | 130 | 130 | 160 | 230 | 230 | 400 | 400 | 700 | 1100 | 1100 | 1500 | 1500 |
| Wt(Kg) | 2.5 | 3 | 5 | 6 | 7.5 | 10 | 15 | 20 | 33 | 60 | 93 | 175 |
PN4.0MPa Main connection dimensions and weight
| DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 130 | 140 | 150 | 180 | 200 | 220 | 250 | 280 | 320 | 400 | 400 | 400 |
| H | 59 | 63 | 75 | 85 | 95 | 107 | 142 | 152 | 178 | 252 | 272 | 342 |
| W | 130 | 130 | 160 | 230 | 230 | 400 | 400 | 700 | 1100 | 1100 | 1500 | 1500 |
| Wt(Kg) | 3 | 4 | 5 | 7 | 9 | 12 | 18 | 28 | 46 | 75 | 106 | 190 |
PN6.4MPa Main connection dimensions and weight
| DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 165 | 190 | 216 | 229 | 241 | 292 | 330 | 356 | 432 | 508 | 559 | 660 |
| H | 59 | 63 | 75 | 97 | 107 | 142 | 152 | 178 | 252 | 272 | 305 | 398 |
| W | 130 | 130 | 160 | 230 | 230 | 400 | 400 | 700 | 1100 | 1100 | 1500 | 1800 |
| Wt(Kg) | 6.5 | 7 | 8 | 12 | 14 | 18 | 28 | 40 | 65 | 98 | 140 | 250 |
PN10MPa Main connection dimensions and weight
| DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 165 | 190 | 216 | 229 | 241 | 292 | 330 | 356 | 432 | 508 | 559 | 660 |
| H | 59 | 63 | 75 | 97 | 107 | 142 | 152 | 178 | 252 | 272 | 305 | 398 |
| W | 130 | 130 | 160 | 230 | 230 | 400 | 400 | 700 | 1100 | 1100 | 1500 | 1800 |
| Wt(Kg) | 6.5 | 7 | 10 | 15 | 18 | 25 | 32 | 46 | 75 | - | - | - |
Product Images
Frequently Asked Questions
Q1: Can you OEM/ODM?
A: Accurately customize according to your needs.
Q2: What can you buy from us?
A: The main products of the company are: sleeve, threaded pipe joints, needle valves, metering valves, ball valves, unloading valves, check valves, filters, back pressure regulator and other related accessories and seamless steel pipes, involving metric, inch size specifications.
Q3: Do YUHAO provide samples?
A: Yes, stored samples are totally free. Please note we do not cover express shipping costs for samples.
Q4: Do YUHAO have a published price list?
A: We do not maintain a published price list due to fluctuating market conditions. Our sales team provides customized quotes based on current market pricing and your specific requirements.
Q5: Which payment terms you can accept?
A: We accept TT, LC, DP, DA, Western Union, or other negotiable payment methods.
