F304L 45 Degree Welded Metal Seal 1/2 Inch Food Industry Elbow Sanitary Pipe
Price:
Negotation
MOQ:
100KGS
Delivery Time:
2-10 work days
Brand:
Yuhao
Product Description
F304L 45 Degree Welded Metal Seal 1/2 Inch Food Industry Elbow Sanitary Pipe
Product Specifications
| Material | Stainless Steel 201 304, 304L, 306, 306L |
| Type | 45 /90/180 Degrees |
| Working Temperature | -325℉~800℉ (-198℃~426℃) |
| Packing | Wooden case, Bags, Pallets |
| Size | 1/8"-2" |
| Customized Support | OEM, ODM, OBM |
| Warranty | 1 year |
| Application | Food processing, wine, brewery, milk, beverage |
| Connection Method | Welding |
Product Description
The Stainless Steel F304L 45-Degree Welded Sanitary Elbow is designed for high-purity applications in the food, beverage, and pharmaceutical industries. Made from premium F304L stainless steel, it offers excellent corrosion resistance and durability.
The 45-degree design ensures smooth flow transition, while the welded metal seal provides a secure, leak-proof connection. Precision-polished to a mirror finish, it prevents bacterial buildup and meets stringent sanitary standards. Ideal for hygienic piping systems, this elbow guarantees reliability, easy cleaning, and long-term performance in demanding environments.
Product Dimensions
| DN | NPS | OD | Nominal Wall Thickness |
|---|---|---|---|
| 6 | 1/8 | 10.3 | - | 1.24 | 1.73 | 2.41 | - | - | - | 1.73 | 1.73 | - | 2.41 |
| 8 | 1/4 | 13.7 | 1.65 | 2.24 | 3.02 | - | - | - | 2.24 | 2.24 | - | 3.02 |
| 10 | 3/8 | 17.1 | - | 1.65 | 2.31 | 3.2 | - | - | - | 2.31 | 2.31 | - | 3.2 |
| 15 | 1/2 | 21.3 | 1.65 | 2.11 | 2.77 | 3.73 | - | - | - | 2.77 | 2.77 | - | 3.73 |
| 20 | 3/4 | 26.7 | 1.65 | 2.11 | 2.87 | 3.91 | - | - | - | 2.87 | 2.87 | - | 3.91 |
| 25 | 1 | 33.4 | 1.65 | 2.77 | 3.38 | 4.55 | - | - | - | 3.38 | 3.38 | - | 4.55 |
| 32 | 1 1/4 | 42.2 | 1.65 | 2.77 | 3.56 | 4.85 | - | - | - | 3.56 | 3.56 | - | 4.85 |
| 40 | 1 1/2 | 48.3 | 1.65 | 2.77 | 3.68 | 5.08 | - | - | - | 3.68 | 3.68 | - | 5.08 |
| 50 | 2 | 60.3 | 1.65 | 2.77 | 3.91 | 5.54 | - | - | - | 3.91 | 3.91 | - | 5.54 |
| 65 | 2 1/2 | 73 | 2.11 | 3.05 | 5.16 | 7.01 | - | - | - | 5.16 | 5.16 | - | 7.01 |
| 80 | 3 | 88.9 | 2.11 | 3.05 | 5.49 | 7.62 | - | - | - | 5.49 | 5.49 | - | 7.62 |
| 90 | 3 1/2 | 101.6 | 2.11 | 3.05 | 5.74 | 8.08 | - | - | - | 5.74 | 5.74 | - | 8.08 |
| 100 | 4 | 114.3 | 2.11 | 3.05 | 6.02 | 8.56 | - | - | - | 6.02 | 6.02 | - | 8.56 |
| 125 | 5 | 141.3 | 2.77 | 3.4 | 6.55 | 9.53 | - | - | - | 6.55 | 6.55 | - | 9.53 |
| 150 | 6 | 168.3 | 2.77 | 3.4 | 7.11 | 10.97 | - | - | - | 7.11 | 7.11 | - | 10.97 |
| 200 | 8 | 219.1 | 2.77 | 3.76 | 8.18 | 12.7 | - | 6.35 | 7.04 | 8.18 | 8.18 | 10.31 | 12.7 |
| 250 | 10 | 273 | 3.4 | 4.19 | 9.27 | 12.7 | - | 6.35 | 7.8 | 9.27 | 9.27 | 12.7 | 12.7 |
| 300 | 12 | 323.8 | 3.96 | 4.57 | 9.53 | 12.7 | - | 6.35 | 8.38 | 9.53 | 10.31 | 14.27 | 12.7 |
| 350 | 14 | 355.6 | 3.96 | 4.78 | - | - | 6.35 | 7.92 | 9.53 | 9.53 | 11.13 | 15.09 | 12.7 |
| 400 | 16 | 406.4 | 4.19 | 4.78 | - | - | 6.35 | 7.92 | 9.53 | 9.53 | 12.7 | 16.66 | 12.7 |
| 450 | 18 | 457 | 4.19 | 4.78 | - | - | 6.35 | 7.92 | 11.13 | 9.53 | 14.27 | 19.05 | 12.7 |
| 500 | 20 | 508 | 4.78 | 5.54 | - | - | 6.35 | 9.53 | 12.7 | 9.53 | 15.09 | 20.62 | 12.7 |
Product Images

Frequently Asked Questions
Q1: Do you have your own factory?
A: Yes, we do. We have our own factory, and we can provide stable stock with competitive price and good quality.
Q2: What is your way of the surface treatment?
A: We can make the special logo, icon or other things you ordered on the product. Whatsoever, we can do as your requirements.
Q3: Do you provide samples? is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q4: How long is your delivery time?
A: Depending on the quantity.
Q5: How long can we receive your quotation?
A: If your information given is complete, our quotation will be given to you within the next working day.
