Drain Valves Mechanical Gate Valve 4 Inches Cast Iron Gateknife Gate Valve
Drain valves mechanical gate valve 4 inches cast iron gateknife gate valve
Drain valves mechanical gate valve 4 inches cast iron gateknife gate valve
Product description:
Soft sealing gate valves, industrial valves, and soft sealing gate valves have gate plates as their opening and closing components. The direction of movement of the gate plate is perpendicular to the direction of the fluid, and the gate valve can only be fully opened and fully closed, and cannot be adjusted or throttled. The gate valve has two sealing surfaces, and the most commonly used mode is that the two sealing surfaces of the gate valve form a wedge shape. The wedge angle varies with the valve parameters, with a nominal diameter of DN50 to DN1200 and a service temperature of ≤ 200 ℃.
Technical parameters:
| Nominal Diameter | DN50~DN1200 |
| Pressure level | 1.6MPa-2.5MPa |
| Main material | QT450, WCB, CF8 |
| Applicable temperature | -0℃ to 80℃; |
| Design manufacturing standard | GB/T32290; GB/T 12232; CJ/T 216 |
| Structure length standard | GB/T12221 |
| Connecting size standard | GB/T17241.6; JB78 |
| Pressure test standard | GB/T13927 |
| Transmission mode | Manual, bevel gear, electric, pneumatic |
| Applicable Medium | Water, steam, gas, oil,etc. |
Drain valves mechanical gate valve 4 inches cast iron gateknife gate valve
Our products have become products of 3-High: high technology, high standard, high quality.
Porfessional selection guidance;
Remote technical support;
Professional presale and aftersales service;
Sample order is acceptable.
Drain valves mechanical gate valve 4 inches cast iron gateknife gate valve
Drain valves mechanical gate valve 4 inches cast iron gateknife gate valve
