0.1t/H-60t/H Capacity Fluidised Bed Roaster Waste Treatment Equipment
Price:
Based on the actual circumstances
MOQ:
a set
Delivery Time:
20-50work days
Brand:
Zoomline
Product Description
16m² 32m² Boiling Roaster Fluidizing Roaster Fluidized Bed Roasting
The boiling roaster, also known as a solid fluidized-bed roaster, uses air at a specific flow rate to carry out intense roasting reactions on powdered materials. During operation, materials remain in continuous motion, resembling the boiling state of a viscous liquid.
Product Specifications
| Attribute | Value |
|---|---|
| Weight | 3.5-98t |
| Capacity | 0.1-60t/h |
| Power | 5.5-180kw |
| Diameter | 900-6400mm |
Available Models
| Model | Diameter (mm) | Capacity (t/h) | Power (kw) | Weight (t) |
|---|---|---|---|---|
| ZLFT-0.6m² | 900 | 0.1-1.2 | 5.5-7.5 | 3.5 |
| ZLFT-1.1m² | 1200 | 0.3-2.7 | 11-15 | 5.9 |
| ZLFT-3m² | 2000 | 1.1-3.5 | 22-30 | 17 |
| ZLFT-5m² | 2600 | 3.8-7.9 | 30-45 | 26 |
| ZLFT-16m² | 4600 | 15-30 | 90-110 | 55 |
| ZLFT-32m² | 6400 | 26-60 | 132-180 | 98 |
Furnace Types
- Straight-cylinder roasters: Primarily used for roasting non-ferrous metal concentrates.
- Roasters with enlarged upper part: Originally designed for crushing ore lumps (raw materials for sulfuric acid production). Later adapted for various floatation ores and sulfur-rich concentrates to improve ore grade.
Key Advantages
- High production intensity due to close contact between air and materials
- Excellent heat transfer efficiency with increased specific surface area (3280-49200 m² per cubic meter)
- Versatile for various raw materials, especially fine-grained materials
- Simple operation with easy mechanization and automation
